Siemens 3WL1110 3-Pole Fixed-Mount Circuit Breaker 1000A 690V

Siemens 3WL1110 3-Pole Fixed-Mount Circuit Breaker 1000A 690V

  • Siemens 3WL1110 3-Pole Fixed-Mount Circuit Breaker 1000A 690V
  • Siemens 3WL1110 3-Pole Fixed-Mount Circuit Breaker 1000A 690V
  • Siemens 3WL1110 3-Pole Fixed-Mount Circuit Breaker 1000A 690V
  • Siemens 3WL1110 3-Pole Fixed-Mount Circuit Breaker 1000A 690V
  • Siemens 3WL1110 3-Pole Fixed-Mount Circuit Breaker 1000A 690V
Siemens 3WL1110 3-Pole Fixed-Mount Circuit Breaker 1000A 690V
Product Details:
Place of Origin: GERMANY
Brand Name: SIEMENS
Model Number: 3WL1110-2BB34-4AN2-Z C22+F31
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $99
Delivery Time: In stock/1-3days
Payment Terms: T/T
Contact Now
Detailed Product Description
Highlight:

Siemens 3WL1110 circuit breaker 1000A

,

fixed-mount circuit breaker 690V

,

3-pole circuit breaker with warranty

3WL1110-2BB34-4AN2-Z C22+F31 SIEMENS fixed-mounted circuit breaker 3-pole
Product Overview

The 3WL1110-2BB34-4AN2-Z C22+F31 is a three-pole air circuit breaker from Siemens' SENTRON 3WL series, designed for reliable low-voltage power distribution and motor protection. This module integrates advanced overcurrent protection, remote monitoring capabilities, and modular design, making it suitable for demanding industrial and commercial applications.

Technical Specifications
Product Series SENTRON 3WL Air Circuit Breaker
Model 3WL1110-2BB34-4AN2-Z with options C22 (Ready Indicator) and F31 (auxiliary release)
Poles 3-pole configuration
Rated Current 1000A (adjustable via ETU 25B electronic trip unit)
Voltage Rating 690V AC, 50/60Hz
Short-Circuit Breaking Capacity (Icu) 55kA at 500V
Protection Functions LSI (Long-delay, Short-delay, Instantaneous) overcurrent protection with adjustable thresholds
Operating Mechanism Motorized/manual operation with spring-charging motor (AC 208-240V or DC 220-250V power supply)
Auxiliary Contacts 2NO+2NC (normally open/closed) for status signaling
Communication Integrated PROFINET/PROFIBUS support (via optional modules)
Diagnostic Features LED status indicators, Web server for remote configuration, Trace function for event-driven analysis
Physical Dimensions 100 mm (W) × 125 mm (H) × 75 mm (D), 0.8 kg weight
Protection Class IP20 (front-panel protection)
Compliance IEC 60947-2, CE, UL, RoHS standards
Environmental Resilience Operating temperature: -25°C to +60°C, Vibration/shock-resistant design
Siemens 3WL1110 3-Pole Fixed-Mount Circuit Breaker 1000A 690V 0
