6ES7322-1BH01-0AA0 SIEMENS Digital output SM 322

SIEMENS  6ES7322-1BH01-0AA0  Digital output SM 322:

SIMATIC S7-300, Digital output SM 322, isolated, 16 DO, 24 V DC, 0.5A, 1x 20-pole, Total current 4 A/group (8 A/module).

The Siemens 6ES7 322-1BH01-0AA0 is a 16-channel digital output module (DO) designed for the SIMATIC S7-300 PLC series. This module is part of the S7-300 I/O system and is widely used in industrial automation applications to control digital actuators such as solenoid valves, contactors, and indicators.

Key Features and Specifications:

Model: 6ES7 322-1BH01-0AA0

Series: SIMATIC S7-300

Function: 16-channel digital output module (24 V DC, 0.5 A per channel)

Output Type:

Voltage Level: 24 V DC

Load Current: 0.5 A per channel (total current per group: 4 A; total module current: 8 A)

Electrical Isolation: Channels are isolated in groups (e.g., 8 channels per group for some variants, but this module typically has 16 channels with isolation properties as per S7-300 standards).

Power Supply:

Backplane Bus: 24 V DC (supplied via the S7-300 rack).

External Load Voltage: 24 V DC (separate from backplane supply).

Response Time:

Signal On: Typically < 1 ms

Signal Off: Typically < 1 ms

Mechanical Design:

Dimensions (W x H x D): Approximately 45 mm x 125 mm x 120.5 mm (width varies slightly based on rack mounting).

Mounting: DIN rail or direct mounting in S7-300 rack.

Weight: Approximately 200 g.

Environmental Specifications:

Operating Temperature: -25°C to +60°C

Storage Temperature: -40°C to +85°C

Protection Class: IP20 (for installation in control cabinets).

LED Indicators:

Channel Status LEDs: Indicate the ON/OFF state of each output channel.

Module Status LEDs: Indicate power, error, and operational status.

Approvals and Certifications:

CE, UL, cUL, GOST-R, and other industrial certifications.

Our Services:

1,All our products are new and original, and of good quality

2,Our prices are very competitive.3.We have a large quantity in stock, so we could help the customers to get the components which are dificult to getAll inquiries will be valued and wil reply in 24 hours.

5.Fast shipping, and good after-sale service

6We will ship the items within 1-3 working days after the payment is received

7,Good package to protect the products.

More Products In Stock:
