6ES7318-3EL00-0AB0 SIEMENS Central processing unit

SIEMENS 6ES7318-3EL00-0AB0 Central processing unit:

SIMATIC S7-300 CPU 319-3 PN/DP, Central processing unit with 1.4MB memory, 1st interface MPI/DP 12 Mbit/s, 2nd interface DP master/slave 3rd interface Ethernet PROFINET, Micro Memory Card required.

Technical Specifications:

1. General Information

Model: 6ES7318-3EL00-0AB0

Series: SIMATIC S7-300

Type: CPU 318-2 PN/DP Central Processing Unit

Application: Suitable for medium to large-scale automation projects requiring distributed configurations using PROFIBUS DP and PROFINET IO.

2. Technical Specifications

Working Memory: 128 KB (user program storage)

Load Memory: Expandable up to 8 MB via SIMATIC Micro Memory Card (MMC)

Interfaces:

1 MPI/DP interface (12 Mbit/s)

2 Ethernet PROFINET interfaces with dual-port switches

Power Supply: 24V DC

Voltage Range: 20.4V to 28.8V DC

Power Consumption: 750 mA (rated), 150 mA (no-load)

3. Performance

Processing Speed:

Bit operation: 0.025 µs

Word operation: 0.03 µs

Fixed-point arithmetic: 0.04 µs

Floating-point arithmetic: 0.16 µs

Block Capacities:

Data Blocks (DB), Function Blocks (FB), Functions (FC): Up to 2,048 each, with a maximum capacity of 64 KB per block

Organization Blocks (OB): Maximum capacity of 64 KB
