Name: 6SL3210-1PE24-5AL0 SIEMENS POWER MODULE PM240-2
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 6SL3210-1PE24-5AL0
Price: 50.00 USD
Availability: InStock

Home > Products > SIEMENS PLC Module >

6SL3210-1PE24-5AL0 SIEMENS POWER MODULE PM240-2

omron module

omron plc module

omron io module

Place of Origin:

GERMANY

Brand Name:

SIEMENS

Model Number:

6SL3210-1PE24-5AL0

Request A Quote

Product Details

Brand:

SIEMENS

Warranty:

1 Year

Highlight:

omron module

omron plc module

omron io module

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

6SL3120-1TE21-8AD0 SIEMENS S120 Single Motor Module Input

Get Best Price

6SE6420-2UD23-0BA1 SIEMENS MICROMASTER 420

Get Best Price

6ES7972-0BB12-0XA0 SIEMENS PROFIBUS DP Bus Connector

Get Best Price

6SL3162-2ME01-0AC0 SIEMENS S120 C/D Type Adapter Cable

Get Best Price

Contact Now

Product Description

6SL3210-1PE24-5AL0 SIEMENS POWER MODULE PM240-2

SIEMENS 6SL3210-1PE24-5AL0 POWER MODULE PM240-2:

SINAMICS G120 POWER MODULE PM240-2 WITH BUILT IN CL. A FILTER WITH BUILT IN BRAKING CHOPPER 3AC380-480V +10/-20% 47-63HZ OUTPUT HIGH OVERLOAD: 18.5KW FOR 200% 3S,150% 57S,100% 240S AMBIENT TEMP -20 TO +50 DEG C (HO) OUTPUT LOW OVERLOAD: 22kW FOR 150% 3S,110% 57S,100% 240S AMBIENT TEMP -20 TO +40 DEG C (LO) 472 X 200 X 237 (HXWXD), FSD PROTECTION IP20 WITHOUT CONTROL UNIT AND PANEL APPROVED FOR CU FIRMWARE- VERSION V4.7 HF8.

Technical Specifications

Parameter	Details
Model Number	6SL3210-1PE24-5AL0
Series	SINAMICS G120 (PM240-2 Power Module)
Rated Power	22 kW (Light Overload), 18.5 kW (Heavy Overload)
Input Voltage	3AC 380-480V +10/-20%, 47-63Hz
Output Current	50A (Rated), 75A (150% Overload for 3 Seconds)
Control Mode	Current Vector Control (High-Precision Speed/Torque Regulation)
Pulse Modulation	PWM (Pulse Width Modulation) for Output Voltage Regulation
Filter	Integrated A-Class Filter (Reduces Electromagnetic Interference)
Brake Function	Integrated Brake Chopper (Supports Dynamic Braking)
Mechanical Design	Compact Book-Size Format (472 * 200 * 237 mm), IP20/UL Open Type
Weight	Approximately 7.85 kg
Operating Temperature	-20°C to +50°C (Heavy Overload), -20°C to +40°C (Light Overload)
Storage Temperature	-25°C to +70°C
Humidity	5% to 95% (Non-Condensing)
Altitude	Up to 1000m (Derating Required Above 1000m)
Vibration/Shock	Conforms to IEC 60068-2-6/27 (Industrial Environment Resistance)
Approvals	CE, UL, cUL, RoHS-Compliant
Compliance	EN 61800-3 (EMC), IEC 61800-5-2 (Safety)
Cooling	Passive (Fan-Free Design)
Mounting	DIN Rail or Direct Cabinet Mounting
Diagnostics	LED Status Indicators, Error Logging, and Debugging via TIA Portal
Communication	PROFINET-PN (Optional Fieldbus Extensions via DRIVE-CLiQ)
Safety Functions	STO (Safe Torque Off) per IEC 61800-5-2
I/O Interface	Configurable Digital/Analog I/O (via Optional Modules)
Optional Modules	Fieldbus Adapters, Encoder Interfaces, Safety Modules
Lifecycle Status	Active (Current Production Model)
