Product Description

LR-ZB100C3P KEYENCE Rectangular W/ M8 Connector Type, 100 Mm

The KEYENCE LR-ZB100C3P is a high-precision CMOS laser sensor designed for industrial automation applications. Part of KEYENCE's LR-Z series, it features a built-in amplifier, rectangular reflective design, and M8 connector, making it ideal for demanding detection tasks such as part presence verification, dimensional measurement, and position monitoring. Its key advantage lies in its distance-setting functionality (BGS/FGS modes), enabling flexible threshold adjustments for diverse applications.

Technical Specifications

Parameter	Details
Model	LR-ZB100C3P
Type	Distance-setting laser sensor (BGS/FGS modes)
Detection Range	35 mm to 100 mm (standard step difference: 1.5 mm at 35-50 mm, 3 mm at 50-100 mm)
Display Resolution	0.2 mm
Light Spot Diameter	2 × 1 mm (at 100 mm detection distance)
Response Time	Switchable (1.5 ms/10 ms/50 ms)
Laser Source	Red laser (660 nm), Class 1 laser product (IEC60825-1, FDA compliant)
Output	PNP open-collector, max 100 mA control current, ≤2 V residual voltage
Power Supply	10-30 VDC (≤450 mW power consumption, 18 mA @24 V, 34 mA @12 V)
Environmental Rating	IP68 (IEC60529), IP69K (DIN40050-9), ECOLAB/Diversey certified
Operating Temperature	-10°C to +50°C (non-freezing)
Vibration Resistance	10-55 Hz, 1.5 mm double amplitude (X/Y/Z directions, 2 hours each)
Shock Resistance	1,000 m/s² (X/Y/Z directions, 6 times each)
Housing Material	SUS316L (body), PES (display), PMMA (lens cover with anti-scratch coating)
Dimensions/Weight	Compact design, ~55 g
