IV3-G500MA KEYENCE Sensor head Standard model Colour AF type

Product Details:

Place of Origin:	Japan
Brand Name:	KEYENCE
Model Number:	IV3-G500MA

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$99
Delivery Time:	In stock/1-3days
Payment Terms:	T/T
Supply Ability:	10

Contact Now

Detailed Product Description

Highlight:

sensor head keyence parts

ip67 keyence parts

compact keyence parts

KEYENCE IV3-G500MA Sensor head Standard model Colour AF type:

The KEYENCE IV3-G500MA is an AI-powered image recognition sensor controller designed for high-precision industrial inspection tasks. Combining a 1/2.9-inch black-and-white CMOS sensor with infrared LED lighting and AI algorithms, it excels in applications such as dimensional measurement, defect detection, position recognition, and barcode reading. Its rugged design and advanced features make it ideal for smart manufacturing and quality control environments.

Technical Specifications:

Parameter	Details
Model	IV3-G500MA
Type	AI image recognition sensor controller (black-and-white CMOS)
Image Sensor	1/2.9-inch CMOS, 1280 × 960 pixels
Light Source	Infrared LED (pulse lighting mode)
Inspection Tools	16 tools (height, area, edge, OCR, etc.)
Program Capacity	128 programs (with SD card) / 32 programs (without SD card)
Image Storage	1000 inspection images (NG/OK)
Data Transmission	SD card, FTP server (BMP/JPEG/IV3P/TXT)
Ethernet	100BASE-TX/10BASE-T, RJ45 connector
I/O Ports	8 inputs (24 VDC, programmable), 8 outputs (NPN/PNP, 50 mA max)
Power Supply	12–24 VDC ±10%, 60 mA max at 24 VDC
Operating Temperature	0°C to +50°C (no freezing)
Humidity	35–85% RH (no condensation)
Protection Class	IP67
Material	Main unit: Zinc die-cast/acrylic/TPU; Connectors: Industrial-grade
Dimensions	Compact design (exact dimensions vary by configuration)

IV3-G500MA KEYENCE Sensor head Standard model Colour AF type 0

Our Services:

1,All our products are new and original, and of good quality.

2,Our prices are very competitive.

3,We have a large quantity in stock, so we could help the customers to get the components which are difficult to get.

4,All inquiries will be valued and will reply in 24.
