Short Circuit Protection SIEMENS PLC Module SIEMENS 1XP8022-10 Manual Motor Protector

SIEMENS 1XP8022-10  manual motor protector :

The Siemens 1XP8022-10 is a manual motor protector (MMP) designed for direct manual starting and stopping of motors, providing reliable overload and short-circuit protection. It is part of Siemens' SIRIUS control product line, offering compact design, adjustable trip settings, and robust performance for industrial applications.

Technical Specifications:

Rated Operational Current (Ie): Adjustable from 0.1–25 A

Tripping Class: Class 10 (standard for general-purpose motors)

Rated Insulation Voltage (Ui): 690 V AC

Rated Impulse Withstand Voltage (Uimp): 8 kV

Mounting: DIN rail (35 mm) or screw mounting

Connection Type: Screw terminals or spring-type terminals

Approvals: UL, CSA, CE, IEC/EN 60947-4-1

Ambient Temperature: -20°C to +60°C

Protection: IP20 (terminal housing)
