1766-L32BWAA ALLEN BRADLEY Relay Module
1766-L32BWAA is a programmable logic controller (PLC) of the MicroLogix 1400 series under Rockwell Automation, which belongs to high-performance, modular industrial control equipment. This model adopts a compact design, supports 24V DC power input, built-in 12 point fast DC 24V digital input, 8-point ordinary DC 24V digital input, and 12 point relay digital output, and is equipped with 4-channel analog voltage input and 2-channel analog voltage output to meet complex signal processing requirements. Its hardware architecture supports expansion module connections, allowing for flexible expansion of I/O points to 136, and is compatible with 1762 MicroLogix expansion I/O modules, suitable for various industrial scenarios. The controller is equipped with a combination port of RS-232/RS-485 and a programming port, supporting communication protocols such as EtherNet/IP, and can seamlessly integrate human-machine interfaces, frequency converters, and other devices to achieve efficient data exchange. In addition, the product integrates high-speed counters, pulse outputs, external interrupts, and C language editing function blocks, supports floating-point data file and program data encryption, and provides advanced functions such as interrupt input and limit switches to ensure the safety and reliability of device operation. With its modular design, powerful communication capabilities, and rich expansion options, 1766-L32BWAA is widely used in fields such as CNC machinery, metallurgy, oil and gas, paper and printing, providing stable and flexible solutions for industrial automation.
Technical specifcations for 1766-L32BWAA
Brand and model Rockwell Automation, model 1766-L32BWAA, belongs to the MicroLogix 1400 series
Input specifications: 12 point fast DC 24V digital input, 8-point regular DC 24V digital input
Output specification: 12 point relay digital output
Analog input/output: 4-channel analog voltage input, 2-channel analog voltage output (some information may not be explicitly mentioned, but it is a common configuration for this model)
Power input AC 120V or 240V power input
The communication interface includes isolated RS-232/485 ports, Ethernet ports, and non isolated RS-232 ports, supporting communication protocols such as EtherNet/IP
The expansion capability can extend up to seven 1762 expansion I/O modules to increase the number of I/O points
The memory has user program storage and user data storage, and the specific capacity may vary depending on the product version
The high-speed counter can have up to 6 embedded 100 kHz high-speed counters (only applicable to DC controllers)
Two serial ports, supporting DH485/DF1/Modbus RTU/DNP3/ASCII protocols
Programming software uses RSLogix 500/Micro programming software (version 8.1 and higher) for programming
Installation method supports panel or DIN rail installation with open shell
Environmental adaptability is suitable for clean and dry industrial environments where the circuit does not exceed Class II overvoltage
Special features include a built-in real-time clock (RTC) that provides time-based control; Support encryption of floating-point data files and program data; Provide programmable limit switch function, etc
