Name: 6ES7522-1BL01-0AB0 SIEMENS SIMATIC S7-1500, Digital Output Module
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 6ES7522-1BL01-0AB0
Price: 50.00 USD
Availability: InStock

Home > Products > SIEMENS PLC Module >

6ES7522-1BL01-0AB0 SIEMENS SIMATIC S7-1500, Digital Output Module

Digital Output SIEMENS PLC Module

IMATIC S7-1500 SIEMENS 6ES7522-1BL01-0AB0

Digital Output SIEMENS 6ES7522-1BL01-0AB0

Place of Origin:

GERMANY

Brand Name:

SIEMENS

Model Number:

6ES7522-1BL01-0AB0

Request A Quote

Product Details

Brand:

SIEMENS

Warranty:

1 Year

Highlight:

Digital Output SIEMENS PLC Module

IMATIC S7-1500 SIEMENS 6ES7522-1BL01-0AB0

Digital Output SIEMENS 6ES7522-1BL01-0AB0

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

6SL3120-1TE21-8AD0 SIEMENS S120 Single Motor Module Input

Get Best Price

6SE6420-2UD23-0BA1 SIEMENS MICROMASTER 420

Get Best Price

6ES7972-0BB12-0XA0 SIEMENS PROFIBUS DP Bus Connector

Get Best Price

6SL3162-2ME01-0AC0 SIEMENS S120 C/D Type Adapter Cable

Get Best Price

Contact Now

Product Description

SIEMENS 6ES7522-1BL01-0AB0 SIMATIC S7-1500 Digital Output Module

The SIMATIC S7-1500 digital output module features 32 channels in groups of 8 with 4A per group, supporting single-channel diagnostics and substitute value functionality. This high-performance module includes switching cycle counters for connected actuators and enables safety-oriented shutdown of load groups up to SIL2 (EN IEC 62061:2021) and Category 3/PL d (EN ISO 13849-1:2015).

Key Features:

32 digital outputs (24V DC/0.5A HF)
Channels grouped in 8 with 4A per group
Single-channel diagnostics capability
Substitute value functionality
Switching cycle counter for actuators
SIL2 (EN IEC 62061:2021) and Category 3/PL d (EN ISO 13849-1:2015) safety compliance
Front connector (screw terminals or push-in) available separately

Technical Specifications:

Model	6ES7522-1BL01-0AB0 (SIMATIC S7-1500 DO 16x24VDC/0.5A HF)
Output Channels	16 digital outputs (source/sink configurable)
Output Voltage	24 V DC (-15% / +20%)
Output Current	0.5 A per channel, 4 A total
Output Delay	0.1-12.5 ms (adjustable via software)
Response Time	< 1 ms (for high-speed outputs)
Signal Indication	16 LEDs for output status display
Isolation	500 V (channel-to-channel and channel-to-ground)
Power Supply	24 V DC (from S7-1500 CPU or external supply)
Backplane Bus Current	130 mA (max)
Mounting	Directly on S7-1500 CPU or expansion modules
Dimensions (W × H × D)	35 mm × 116 mm × 72 mm
Weight	Approx. 100 g
Operating Temperature	-20°C to +60°C
Storage Temperature	-40°C to +85°C
Humidity	5-95% RH (non-condensing)
Protection Class	IP20
Approvals	UL, CE, C-Tick, and marine approvals (DNV, ABS)

Packing & Delivery:

100% brand new and original factory sealed
1 year warranty
Original packaging with cartons
Shipped within 3-7 days after payment
All goods tested before shipment
