R88D-KN02H-ECT OMRON high-performance servo drive

Omron R88D-KN02H-ECT  high-performance servo drive

The OMRON R88D-KN02H-ECT is a high-performance servo drive designed for precision motion control in industrial automation applications. As part of the Accurax G5 series, it integrates advanced digital control technology and OMRON's proprietary servo algorithms to deliver exceptional dynamic response, positioning accuracy, and energy efficiency. This model is engineered for single-axis control, supporting AC servo motors with a rated output of 2.0A at 240VAC (200W load capacity), making it suitable for moderate to high-duty automation tasks.

Technical Specifications:

Model: R88D-KN02H-ECT

Series: Accurax G5

Control Type: AC Servo Drive (Single-Axis)

Rated Output: 2.0A (240VAC), 200W

Input Voltage: 200–240VAC (±10% tolerance)

Response Frequency: 1.5kHz (dynamic), 30μs (command processing)

Positioning Resolution: Up to 1,048,576 pulses/rev (via encoder feedback)

Communication: EtherCAT, USB 2.0

Braking: Regenerative (built-in resistor optional)

Ambient Conditions: 0–55°C operation, 20–90%RH (non-condensing)

Vibration/Shock: 2G RMS (10–55Hz), 15G (11ms duration)

MTBF: 120,000 hours (per MIL-HDBK-217F)

Application Examples:

Precision Machining: Driving spindle motors in CNC lathes and milling machines.

Robotics: Controlling joint actuators in SCARA and 6-axis robots.

Material Handling: Positioning conveyors and pick-and-place systems in packaging lines.

Semiconductor: Aligning wafer stages in photolithography equipment.

Textile Machinery: Synchronizing loom mechanisms for high-speed weaving.
