FEN-31 ABB HTL encoder interface module

ABB FEN-31  HTL encoder interface module

The ABB FEN-31 is an HTL encoder interface module designed to bridge high-resolution encoders with industrial automation systems, such as ACS880 variable frequency drives (VFDs). Engineered for precision control applications, this module converts HTL (push-pull) encoder signals into TTL-level RS422 outputs, enabling real-time feedback for motor speed, position, and direction monitoring. Its robust design ensures reliable operation in harsh industrial environments, while flexible power options and signal compatibility make it adaptable to diverse automation setups. The FEN-31 is a critical component for industries requiring high-accuracy motion control, including material handling, robotics, and process automation.

Technical Specifications:

1. Model: FEN-31 HTL Encoder Interface
2. Signal Compatibility:
   • Input: Supports HTL (push-pull) encoder signals, including differential, single-ended, collector-open, and emitter-open configurations.
   • Output: TTL RS422 signals (A/B/Z channels) with 10–15 μs pulse rise time.
3. Power Supply:
   • Internal: 15 VDC/24 VDC via X81 terminal block, rated for 200 mA (encoder power).
   • External: Optional 5–24 VDC input for standalone operation.
4. Environmental Ratings:
   • Operating Temperature: -25°C to +70°C (derating above 40°C).
   • Storage Temperature: -40°C to +85°C.
   • Humidity: 5%–95% RH (non-condensing).
   • IP Rating: IP20 (front panel), IP30 (enclosed mounting).
5. Mechanical Specifications:
   • Dimensions: 110 mm (H) × 35 mm (W) × 100 mm (D).
   • Mounting: DIN rail or panel-mount compatible.
   • Weight: 220 g.
6. Electrical Isolation:
   • Channel-to-Channel: 500 VDC (signal/power isolation).
   • Encoder-to-System: 1500 VDC (galvanic isolation).
7. Cable Handling:
   • Max. Cable Length: 100 m (shielded twisted pair for HTL input).
   • Connector Type: Removable terminal blocks for encoder/power wiring.
8. Safety Certifications:
   • Compliance with IEC 61800-5-1 (adjustable speed electrical drive systems).
   • CE, UL, and cUL listed for industrial machinery.
