1762-IF4 MicroLogix series 4-channel current/voltage analog input module

1762-IF4 MicroLogix series 4-channel current/voltage analog input module

  • 1762-IF4 MicroLogix series 4-channel current/voltage analog input module
  • 1762-IF4 MicroLogix series 4-channel current/voltage analog input module
1762-IF4 MicroLogix series 4-channel current/voltage analog input module
Product Details:
Place of Origin: US
Brand Name: Allen Bradley
Model Number: 1762-IF4
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $99
Packaging Details: New sealed
Delivery Time: In stock/1-3days
Payment Terms: T/T
Supply Ability: 5000
Contact Now
Detailed Product Description
Applicantions: Industrial Automation Brand: Allen Bradley
Rated Voltage: 220V Protection Level: IP65
Product Certification: CCC, UL

1762-IF4  ALLEN BRADLEY  Relay Module

1762-IF4 is a MicroLogix series 4-channel current/voltage analog input module launched by Allen Bradley brand under Rockwell Automation, designed specifically for industrial automation scenarios. This module supports 4-20mA current signal and -10 to 10V DC voltage signal input, compatible with MicroLogix 1100, 1200, and 1400 controllers. It achieves 16 bit high-precision data acquisition through a Δ - ∑ converter, with a resolution of 0.0015%. Its four differential input channels can be independently configured as current or voltage modes, covering a wide range of -21 to 21mA and -10.5 to 10.5V, meeting the requirements for temperature, pressure, flow and other sensor signal access. The module adopts a compact design (90 × 87 × 40mm), supports DIN rail or panel installation, and achieves communication between modules through flat ribbon cables. It can be expanded to form a distributed control system with 7 I/O modules. The data format supports raw values, proportional values, and PID proportional output, and the DIP switch configuration simplifies on-site debugging. The module is equipped with a finger safe terminal cover that meets the overvoltage Class II standard. It should be installed in a non hazardous dry environment and equipped with electrostatic discharge protection. Its typical application scenarios include process control, factory automation, and machine vision systems. It improves system control accuracy through high-precision analog signal acquisition and supports on-site firmware upgrades to adapt to future functional expansion requirements. It is a core component for enhancing MicroLogix controller I/O capabilities in the field of industrial automation.


Technical specifcations for 1762-IF4

Core functions and technical parameters

Channel and signal type: Supports 4-channel differential input, can receive 4-20mA current signal or -10 to 10V DC voltage signal, with a full-scale range extended to -21 to 21mA current and -10.5 to 10.5V voltage, suitable for various sensor outputs.
Conversion accuracy: Using a Δ - ∑ converter with a resolution of 16 bits to ensure the accuracy of data acquisition.
Compatibility and Scalability: Compatible with MicroLogix 1100, 1200, 1400 controllers, supporting up to 7 expansion modules (such as MicroLogix 1400, which can connect 7 modules), connected through flat ribbon cables to enhance system I/O capabilities.
Installation method: Supports DIN rail or panel installation, compact size (90mm × 87mm × 40mm), suitable for space limited scenarios.
Configuration flexibility: Input signal types can be selected through DIP switches, and data formats can be set as raw values, proportional values, or PID ratios to meet different application requirements.
Application scenarios and advantages

Industrial automation: widely used in process control (such as temperature, pressure, flow monitoring), factory automation, and machine vision systems, providing high-precision analog signal acquisition.
Environmental adaptability: It needs to be installed in a non hazardous, dry, and clean environment, comply with overvoltage Class II standards, have anti-static discharge design, and ensure stable operation.
Maintenance and Upgrade: Supports on-site firmware upgrades, expands functionality without the need for hardware replacement, and reduces maintenance costs.
Technical details and certification

Power and Communication: Receive 24V DC power through a 5-bus interface and use a shielded cable from Baitong 8716 to reduce interference. The typical data update time is 130-530 milliseconds.
Safety regulations: Compliant with North American hazardous location certification, users need to assess the safety of their application scenarios on their own.
Market positioning and user evaluation

Brand and Origin: Allen Bradley brand from the United States, represented by distributors such as Wuhan Zhengrong and Fuzhou Jufuxing, with a reference price of approximately 840 RMB.
User feedback: The module has been praised for its high precision, stability, and compatibility, especially in distributed control systems that require flexible I/O expansion.
summarize
1762-IF4 is a high-performance analog input module designed specifically for industrial automation. With its multi-channel support, high-precision conversion, flexible configuration, and strong scalability, it has become a key component in the MicroLogix controller ecosystem, suitable for industrial scenarios with strict requirements for data acquisition accuracy and system reliability.
