6AV21240MC010AX0 high-performance human-machine interface

Siemens 6AV21240MC010AX0 (actual model 6AV2124-0MC01-0AX0, may have a typo) is a high-performance human-machine interface (HMI) from the SIMATIC HMI TP1200 Comfort series, designed specifically for industrial automation scenarios and suitable for complex control and monitoring tasks. This product is equipped with a 12.1-inch widescreen TFT display with a resolution of 1280 × 800 pixels and supports 16 million color displays, providing a clear visual experience, especially suitable for industrial scenes that require high-precision visualization. Its core interaction method is touch screen operation, combined with 34 function buttons and LED indicator lights, which can achieve intuitive and efficient human-computer interaction, even wearing gloves can accurately operate.

In terms of technical specifications, the product is equipped with the Windows CE 6.0 operating system, built-in 12MByte project configuration memory, and supports efficient configuration development for WinCC Comfort V11 and above versions. The interface configuration is rich, including 2 PROFINET ports (with integrated switch), 1 RS422/485 interface, 2 USB interfaces, and 2 SD card slots. It supports multiple communication protocols such as PROFIBUS-DP, MPI, EtherNet/IP, and MODBUS, and can seamlessly connect with S7-200/300/400 series PLCs to achieve high-speed data exchange and control instruction transmission.
In terms of application fields, this product is widely used in industrial automation control systems, such as production line monitoring, material conveying, packaging machinery, and distributed control systems. It is particularly suitable for scenarios that require high precision, high reliability, and multi protocol compatibility, such as automotive manufacturing, food and beverage, and pharmaceuticals. User feedback shows that its stable operation, strong communication capability, and high configuration efficiency can significantly improve the efficiency and maintainability of industrial control systems, making it the preferred solution for complex industrial automation applications.

Display screen: 12.1-inch widescreen TFT display screen with a resolution of 1280 × 800 pixels, supporting 16 million color display, providing a clear visual experience, suitable for complex industrial control interfaces.
Interaction mode: Supports touch screen operation, fast response speed, high accuracy, and can be operated even with gloves. It is also equipped with 34 function buttons and LED indicator lights to meet diverse operation needs.
Technical specifications and performance

Operating System and Configuration Software: Equipped with Windows CE 6.0 operating system, supporting WinCC Comfort V11 and above versions for configuration development, providing powerful data processing and interface design capabilities.
Interface and Communication Protocol: Equipped with 2 PROFINET ports (with integrated switch), 1 RS422/485 interface, 2 USB interfaces, and 2 SD card slots, supporting various communication protocols such as PROFIBUS-DP, MPI, EtherNet/IP, MODBUS, etc., achieving seamless connection with S7-200/300/400 series PLCs and other devices.
Storage and Scalability: Built in 12MByte project configuration memory, supports SD card expansion, meets large-scale project configuration and data processing requirements.
Environmental adaptability

Protection level: The front panel reaches IP65 protection level (compliant with NEMA4/4X standards), and the back is IP20, effectively dustproof and waterproof.
Temperature range: storage temperature -20 ℃ to+60 ℃, operating temperature 0 ℃ to+50 ℃ (vertical installation) or 0 ℃ to+40 ℃ (inclined installation), suitable for various industrial environments.
Relative humidity: can withstand up to 90%, ensuring stable operation in humid environments.
machine design

Installation size: The opening size is 434 × 269mm, the shell size is 454 × 289 × 65mm, and the weight is about 5.66kg. It supports vertical installation and saves space.
Structural design: Modular design, easy to maintain and upgrade, reducing overall cost of ownership.
Functional Features

Brightness adjustment: Supports 0-100% brightness adjustment to adapt to different lighting environments.
Archive/Script Function: Supports data archiving and script writing, enhancing system flexibility.
Multimedia support: Built in PDF/Word/Excel viewer and Media Player to meet diverse application needs.
Energy management: Optimize energy consumption through PROFIenergy or HMI projects to achieve green energy conservation.
Backlight lifespan: LED backlight technology has a lifespan of up to 80000 hours, reducing maintenance costs.
Language support: Supports 32 configurable languages, including Asian character sets, suitable for multilingual operation interfaces.
Certification: Passed multiple international certifications such as ATEX 2/22, GL, ABS, cULus, FM Class I Div.2, suitable for harsh environments such as explosion-proof areas and ships.
application area

Widely used in industrial automation control systems, such as production line monitoring, material conveying, packaging machinery, and distributed control systems, it is particularly suitable for scenarios that require high precision, high reliability, and multi protocol compatibility, such as automotive manufacturing, food and beverage, pharmaceutical and other industries.
