KEYENCE SZ-V04 Type 3 Safety Laser Scanner
Product Description: KEYENCE SZ-V04
The KEYENCE SZ-V04 is a high-precision laser displacement sensor designed for industrial automation and precision measurement applications. Belonging to the SZ-V series, this sensor utilizes laser triangulation technology to perform non-contact measurements of distance, position, dimensions, or vibration. It delivers microscopic accuracy, high-speed sampling, and robust environmental resistance, making it ideal for quality control, robotics, semiconductor manufacturing, and advanced R&D tasks.
Technical Specifications:
| Category |
Specification |
| Model |
SZ-V04 |
| Sensor Type |
Laser Displacement Sensor (Laser Triangulation Principle) |
| Measurement Principle |
Laser Triangulation (Emission and Reflection Detection) |
| Measurement Range |
Typical Range: 0–40 mm (adjustable depending on model; extended ranges available) |
| Resolution |
Up to 0.1 μm (micron-level precision, dependent on surface reflectivity) |
| Sampling Rate |
Up to 50 kHz (high-speed mode for dynamic measurements) |
| Light Source |
Visible Red Laser (Wavelength: 655–670 nm) |
| Output Type |
Analog Voltage (0–5 V / 0–10 V), Digital (RS-485, EtherCAT, Ethernet/IP) |
| Protection Rating |
IP67 (dustproof and waterproof for industrial environments) |
| Operating Temperature |
0°C to +50°C (standard industrial range) |
| Storage Temperature |
-20°C to +60°C |
| Power Supply |
DC 12–24 V (standard industrial compatibility) |
| Mounting Method |
Fixed bracket installation; requires perpendicular alignment to target surface |
| Compatibility |
Multi-sensor synchronization; compatible with PLCs, robots, and data systems |
| Certifications |
CE, RoHS, UL compliant |
Features:
Ultra-High Precision:
Micron-level resolution (0.1 μm) for critical applications like semiconductor inspection and micro-component analysis.
High-Speed Sampling:
50 kHz sampling rate supports real-time monitoring in high-speed production lines (e.g., electronics assembly).
Multi-Output Compatibility:
Analog and digital outputs (EtherCAT, Ethernet/IP) for seamless integration with industrial control systems.
Environmental Durability:
IP67-rated housing resists dust, oil, and water splashes, ensuring reliability in harsh environments.
Anti-Interference Design:
Built-in optical filters minimize ambient light interference (e.g., sunlight, fluorescent lamps).
User-Friendly Interface:
Configurable via PC software or front-panel buttons for easy setup and maintenance.
Applications:
Industrial Automation:
Robot path calibration, conveyor height detection, and assembly precision monitoring.
Precision Manufacturing:
Wafer thickness measurement, PCB warpage analysis, and micro-component dimension verification.
Quality Inspection:
Automotive component gap measurement, tire surface defect detection, and packaging flatness checks.
R&D and Laboratory Use:
Material deformation analysis, vibration frequency monitoring, and scientific micro-displacement studies.
Notes:
Target Surface Adaptability:
Highly reflective or transparent surfaces (e.g., glass, mirrors) may require laser power adjustment or diffusive coatings.
Alignment Requirements:
Sensor must be perpendicular to the target surface to avoid measurement errors.
Ambient Light Avoidance:
Shield from direct exposure to strong light sources (e.g., sunlight, halogen lamps).
Communication Protocol Compatibility:
Digital versions require confirmation of protocol compatibility (e.g., EtherCAT) with host systems.
Our Services:
1.All our products are new and orginal, and of good quality
2.Our prices are very competitive.
3.We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.
4.All inquiries will be valued and will reply in 24.
Packing & Delivery:
1.100% brand New and Original Factory Seal!
2.Warranty:1 year
3.Package: Original packing with cartons.
4.Delivery time: Shipped in 3-7 days after payment
5.All the goods will be tested before shipment
