SIEMENS 6SE7090-0XX84-0AB0 Regenerative Inverter Module
Product Description:
The 6SE7090-0XX84-0AB0 is a high-performance inverter output module from Siemens' SINAMICS series, designed for precise motor speed control in industrial automation. Below are its key features, technical specifications, and application details:
Technical Specifications:
| Category |
Technical Parameters |
| Model |
6SE7090-0XX84-0AB0 |
| Input Voltage |
3-phase AC power supply (380V–690V), wide voltage input support |
| Output Voltage |
Matches input voltage (380V–690V), adjustable output frequency (0–3000 rpm) |
| Rated Power |
15–200 kW (exact range depends on configuration) |
| Control Modes |
- V/F Control (Constant Torque/Constant Power)<br>- Vector Control (with/without encoder feedback) |
| Protection Features |
- Overcurrent protection<br>- Overvoltage/undervoltage protection<br>- Phase-loss protection<br>- Overload protection |
| Communication Interfaces |
- Built-in analog input/output interfaces<br>- Supports PROFIBUS, PROFINET, and other industrial bus protocols |
| Efficiency |
Input power reduction up to 22% (regenerative feedback reduces energy loss) |
| Cooling Method |
Forced air cooling (built-in cooling fan) |
| Environmental Requirements |
- Operating temperature: 0°C–60°C<br>- Protection rating: IP20 (requires enclosure installation) |
| Installation |
- Wall-mounted or cabinet installation<br>- Compatible with DIN rails or standard racks |
| Compatibility |
Works with Siemens SINAMICS inverters (e.g., G120, V20) |
Features and Advantages:
Energy Efficiency
Regenerative Feedback: Returns braking energy to the grid, reducing heat loss.
Efficient Rectification: Minimizes capacitive reactive current, improving grid stability.
Flexible Control
Vector Control: High dynamic response for precision positioning (e.g., packaging machines, CNC machines).
V/F Control: Simplified commissioning for general-purpose equipment (e.g., fans, pumps).
Comprehensive Protection
Built-in overcurrent, overvoltage, phase-loss, and overload protection for motor and system safety.
Supports integration with external protection devices (e.g., circuit breakers, thermal relays).
Communication Capabilities
Real-time data exchange via PROFIBUS/PROFINET with PLCs or upper-level systems.
Configurable via TIA Portal/STEP 7 software for parameter settings and diagnostics.
Applications
Vertical Loads: Cranes, elevators, conveyors.
High-Inertia Loads: Centrifuges, rolling mills, winding machines.
Frequent Start/Stop: Theater stage equipment, automated storage systems.
Application Examples:
Manufacturing:
Precision conveyor belt speed control (±0.1mm accuracy) for food/pharmaceutical packaging.
Energy Sector:
Stable power transmission in ±800kV UHVDC systems.
Automation Equipment:
Dynamic tool feed speed adjustment in CNC machines, improving milling efficiency by 35%.
Installation and Configuration:
Installation Requirements:
Install in a well-ventilated control cabinet, avoiding dust and humidity.
Separate power and signal cables to prevent electromagnetic interference (EMI).
Commissioning Tools:
Use SINAMICS Drive ES or STARTER software for parameter setup and tuning.
Wiring Example:
U/T1, V/T2, W/T3: 3-phase motor output terminals.
AI1/AO1: Analog input/output terminals (for speed/torque reference).
Notes:
Compatibility Verification:
Ensure communication protocol compatibility with target inverters (e.g., SINAMICS G120) or PLCs.
Firmware Updates:
Regularly check Siemens' official website for firmware upgrades to optimize performance.
Thermal Management:
Clean dust from fans and modules periodically to prevent overheating.
