SIEMENS 6SL3210-1KE22-6UB1 G120 Inverter Power Module
Product Description:
The 6SL3210-1KE22-6UB1 is a high-performance Power Module from Siemens' SINAMICS G120 series, designed for precise speed and torque control of three-phase AC motors in industrial automation.
Technical Specifications:
| Category |
Technical Parameters |
| Model |
6SL3210-1KE22-6UB1 |
| Input Voltage |
3-phase AC power supply (380V–480V or 500V–690V, depending on configuration) |
| Output Voltage |
Matches input voltage (380V–690V), output frequency range 0–3000 rpm |
| Rated Power |
15 kW–22 kW (exact range depends on configuration) |
| Control Modes |
- V/F Control (Constant Torque/Constant Power)<br>- Vector Control (with/without encoder feedback) |
| Protection Features |
- Overcurrent protection<br>- Overvoltage/undervoltage protection<br>- Phase-loss protection<br>- Overload protection<br>- Short-circuit protection |
| Communication Interfaces |
- Built-in digital input/output interfaces<br>- Expandable with PROFIBUS/PROFINET modules |
| Efficiency |
Input power reduction up to 20% (using efficient IGBT technology and regenerative feedback) |
| Cooling Method |
Forced air cooling (built-in cooling fan) |
| Environmental Requirements |
- Operating temperature: -10°C–50°C (wide temperature range)<br>- Protection rating: IP20 (requires enclosure installation) |
| Installation |
- Wall-mounted installation<br>- Compatible with DIN rails or standard cabinets |
| Compatibility |
Works with SINAMICS G120 control units (e.g., CU240E, CU250S) |
Features and Advantages:
Energy Efficiency
Regenerative Feedback: Returns braking energy to the grid, reducing heat loss.
IGBT Inverter Technology: Minimizes switching losses, achieving conversion efficiency >96%.
Flexible Control
Vector Control: High dynamic response (speed accuracy ±0.1%, torque response <10ms).
V/F Control: Simplified commissioning for general-purpose equipment (e.g., fans, pumps).
Comprehensive Protection
Built-in overcurrent, overvoltage, phase-loss, short-circuit, and overload protection for motor and system safety.
Supports integration with external protection devices (e.g., circuit breakers, thermal relays).
Communication Capabilities
Real-time data exchange via PROFIBUS/PROFINET with PLCs or upper-level systems.
Configurable via TIA Portal/STARTER software for parameter settings and diagnostics.
Applications
Vertical Loads: Cranes, elevators, conveyors.
High-Inertia Loads: Centrifuges, rolling mills, winding machines.
Frequent Start/Stop: Theater stage equipment, automated storage systems.
Application Examples:
Manufacturing:
Dynamic spindle speed adjustment in CNC machines, improving machining accuracy to ±0.01mm.
Energy Sector:
Energy-efficient pump station control in oil pipelines (18% energy savings).
Automation Equipment:
High-speed sorting systems with servo motor drive, response time <5ms.
Installation and Configuration:
Installation Requirements:
Install in a well-ventilated control cabinet, avoiding dust and humidity.
Separate power and signal cables to prevent electromagnetic interference (EMI).
Commissioning Tools:
Use SINAMICS Drive ES or STARTER software for parameter setup and tuning.
Wiring Example:
U/T1, V/T2, W/T3: 3-phase motor output terminals.
DI/DO: Digital input/output terminals (for start/stop control, fault signal feedback).
Notes:
Compatibility Verification:
Ensure firmware version compatibility with control units (e.g., CU240E).
Firmware Updates:
Regularly check Siemens' official website for firmware upgrades to optimize performance.
Thermal Management:
Clean dust from fans and modules periodically to prevent overheating.
