SIEMENS 6AV2123-2MB03-0AX0 Human-Machine Interface (HMI)
Product Description:SIEMENS 6AV2123-2MB03-0AX0
The 6AV2123-2MB03-0AX0 is a 7-inch color touch panel from Siemens' SIMATIC HMI series, designed for industrial automation applications. It belongs to the KTP 700 Basic family and serves as a compact Human-Machine Interface (HMI) for monitoring and controlling machinery and processes in manufacturing, process control, and other industrial environments.
Technical Specifications Reference
| Category |
Specification |
| Display |
- Size: 7-inch diagonal TFT color LCD<br>- Resolution: 800 x 600 pixels (SVGA)<br>- Brightness: ≥ 300 cd/m²<br>- Touchscreen: Resistive or Capacitive (model-dependent) |
| Communication |
- 1x PROFINET interface (RJ45)<br>- Optional serial interface (RS232/485)<br>- Protocols: PROFINET IRT, PROFINET, Modbus TCP, EtherNet/IP |
| Processor & Memory |
- CPU: ARM-based processor<br>- RAM: Up to 128 MB<br>- Flash Memory: 128 MB for project storage |
| Power Supply |
- DC 24V ±20% (standard model)<br>- Power Consumption: ≤ 15W (typical) |
| Environmental Conditions |
- Operating Temperature: 0°C to +50°C (standard), -20°C to +60°C (extended)<br>- Storage Temperature: -40°C to +70°C<br>- Humidity: 10% to 95% RH (non-condensing) |
| Certifications |
CE, UL, CSA, FCC, RoHS, IP65-rated front panel |
| Mounting |
Panel mounting (DIN rail or wall-mount compatible) |
| Software Compatibility |
- SIMATIC WinCC Advanced (formerly WinCC flexible)<br>- TIA Portal integration |
| Additional Features |
- Alarm logging and data archiving<br>- Multi-language support<br>- Remote access via PROFINET<br>- Password protection and user administration |
Key Features:
Industrial-Grade Durability:
IP65-rated front panel for protection against dust and water ingress.
Designed for harsh industrial environments (e.g., vibration, temperature fluctuations).
Seamless PLC Integration:
Optimized for use with Siemens S7-1200/S7-1500 PLCs.
Supports OPC UA for cross-vendor communication.
User-Friendly Interface:
Intuitive GUI design tools for custom HMI screens.
Real-time process visualization, alarms, and diagnostics.
Connectivity Flexibility:
PROFINET interface for high-speed industrial Ethernet communication.
Optional serial interface for legacy systems.
Energy Efficiency:
Low power consumption (≤ 15W) for reduced operational costs.
Applications:
Machine control (packaging, textile, and assembly systems)
Process monitoring (chemical, food & beverage, water treatment)
Automation systems requiring compact HMI solutions
Notes:
Model Confirmation: The 6AV2123-2MB03-0AX0 corresponds to the KTP 700 Basic PN variant. For detailed specifications, refer to Siemens’ official documentation.
