Name: 6ES7338-4BC01-0AB0 SIEMENS SIMATIC S7-300, Signal Module
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 6ES7338-4BC01-0AB0
Price: 50.00 USD
Availability: InStock

Home > Products > SIEMENS PLC Module >

6ES7338-4BC01-0AB0 SIEMENS SIMATIC S7-300, Signal Module

SIEMENS S7-300 position input module

SM 338 module with warranty

PLC position input module 6ES7338

Place of Origin:

GERMANY

Brand Name:

SIEMENS

Model Number:

6ES7338-4BC01-0AB0

Request A Quote

Product Details

Highlight:

SIEMENS S7-300 position input module

SM 338 module with warranty

PLC position input module 6ES7338

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

6SL3120-1TE21-8AD0 SIEMENS S120 Single Motor Module Input

Get Best Price

6SE6420-2UD23-0BA1 SIEMENS MICROMASTER 420

Get Best Price

6ES7972-0BB12-0XA0 SIEMENS PROFIBUS DP Bus Connector

Get Best Price

6SL3162-2ME01-0AC0 SIEMENS S120 C/D Type Adapter Cable

Get Best Price

Contact Now

Product Description

6ES7338-4BC01-0AB0 SIEMENS SIMATIC S7-300, Signal Module

SIEMENS 6ES7338-4BC01-0AB0 SIMATIC S7-300, Signal Module:

SIMATIC S7-300, Signal module for 3 SSI encoders for reading in the position value with 2 FREEZE inputs, 1x 20-pole Supports isochronous mode.

The 6ES7338-4BC01-0AB0 is a SM 338 position input module from Siemens' SIMATIC S7-300 series, designed for precise position detection in industrial automation. This module supports three SSI (Synchronous Serial Interface) encoders, providing 13-bit resolution positioning data with two FREEZE input terminals for value locking. It integrates clock synchronization and is housed in a compact form factor (40 mm width, 125 mm height). The module connects via a 20-pin front connector and is suitable for applications requiring dynamic position feedback, such as CNC machines, automated assembly lines, and industrial robots.

Technical Specifications

Product Series	SIMATIC S7-300 SM 338 Position Input Module
Encoder Support	3x SSI encoders, 13-bit resolution
Input Ranges	Voltage: 0-10 V (selectable) Current: 4-20 mA (selectable)
Input Delay	300 μs (at nominal voltage)
Power Supply	24 V DC (L+: 100 mA; Backplane: 160 mA)
Sensor Power	24 V DC, 900 mA output
Power Loss	3 W (typical)
Connection	20-pin front connector, shielded encoder wires (max. 320 m @ 125 kHz)
Diagnostic Features	Alarm reporting, non-isolated
Configuration	STEP 7 software for parameterization (encoder type, data format, transmission rate)
Environmental	-20°C to 60°C operating temperature, RoHS compliant
Physical Dimensions	40 mm (W) × 125 mm (H) × 120 mm (D), 235 g weight
Application Areas	High-precision position control in machinery, robotics, and process automation

Packing & Delivery

100% brand New and Original Factory Seal!
Warranty: 1 year
Package: Original packing with cartons
Delivery time: Shipped in 3-7 days after payment
All the goods will be tested before shipment
