Name: 6ES7322-1HH01-0AA0 SIEMENS SIMATIC S7-300, Digital Output SM 322
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 6ES7322-1HH01-0AA0
Price: 50.00 USD
Availability: InStock

Home > Products > SIEMENS PLC Module >

6ES7322-1HH01-0AA0 SIEMENS SIMATIC S7-300, Digital Output SM 322

SIEMENS S7-300 digital output module

16DO PLC module with warranty

SIEMENS 6ES7322-1HH01-0AA0 module

Place of Origin:

GERMANY

Brand Name:

SIEMENS

Model Number:

6ES7322-1HH01-0AA0

Request A Quote

Product Details

Highlight:

SIEMENS S7-300 digital output module

16DO PLC module with warranty

SIEMENS 6ES7322-1HH01-0AA0 module

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

6SL3120-1TE21-8AD0 SIEMENS S120 Single Motor Module Input

Get Best Price

6SE6420-2UD23-0BA1 SIEMENS MICROMASTER 420

Get Best Price

6ES7972-0BB12-0XA0 SIEMENS PROFIBUS DP Bus Connector

Get Best Price

6SL3162-2ME01-0AC0 SIEMENS S120 C/D Type Adapter Cable

Get Best Price

Contact Now

Product Description

SIEMENS 6ES7322-1HH01-0AA0 SIMATIC S7-300, Digital Output SM 322

The 6ES7322-1HH01-0AA0 is a digital output module from Siemens' SIMATIC S7-300 series, part of the SM 322 family. Designed for reliable actuator control in industrial automation, this module features 16 isolated digital output channels with 24V DC transistor outputs. It supports potential isolation to ensure signal integrity and reduce electromagnetic interference.

The module is housed in a compact form factor (40 mm width) and connects via a 40-pin front connector, suitable for central or distributed configurations in control cabinets. It supports hot-swapping for seamless maintenance and includes diagnostic LEDs for channel status monitoring.

Technical Specifications

Product Series	SIMATIC S7-300 SM 322 Digital Output Module
Output Channels	16 digital outputs (24V DC, transistor type)
Output Type	Isolated transistor outputs (sink/source configurable)
Voltage/Current	24 V DC, 0.5 A per channel (max. 4 A per group)
Isolation	Channel-to-channel and channel-to-backplane isolation
Power Supply	24 V DC (backplane-powered)
Power Loss	3 W (typical)
Diagnostic Features	LED indicators for channel status and faults, diagnostic interrupts
Configuration	STEP 7 software for parameterization (output type, data format)
Connection	40-pin front connector, shielded cables (max. 320 m @ 125 kHz)
Environmental	-20°C to 60°C operating temperature, RoHS compliant
Physical Dimensions	40 mm (W) × 125 mm (H) × 120 mm (D), 235 g weight
Protection	IP20 rating, overcurrent and short-circuit protection
Compliance	CE, UL, and RoHS standards
Application Areas	Industrial automation, discrete manufacturing, and actuator control requiring high-channel-density outputs
