Name: 6ES7322-1BL00-0AA0 SIEMENS SIMATIC S7-300, Digital Output SM 322
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 6ES7322-1BL00-0AA0
Price: 50.00 USD
Availability: InStock

Home > Products > SIEMENS PLC Module >

6ES7322-1BL00-0AA0 SIEMENS SIMATIC S7-300, Digital Output SM 322

Siemens S7-300 digital output module

32DO 24V DC PLC module

Siemens PLC module with warranty

Place of Origin:

GERMANY

Brand Name:

SIEMENS

Model Number:

6ES7322-1BL00-0AA0

Request A Quote

Product Details

Highlight:

Siemens S7-300 digital output module

32DO 24V DC PLC module

Siemens PLC module with warranty

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

6SL3120-1TE21-8AD0 SIEMENS S120 Single Motor Module Input

Get Best Price

6SE6420-2UD23-0BA1 SIEMENS MICROMASTER 420

Get Best Price

6ES7972-0BB12-0XA0 SIEMENS PROFIBUS DP Bus Connector

Get Best Price

6SL3162-2ME01-0AC0 SIEMENS S120 C/D Type Adapter Cable

Get Best Price

Contact Now

Product Description

6ES7322-1BL00-0AA0 SIEMENS SIMATIC S7-300, Digital Output SM 322

SIEMENS 6ES7322-1BL00-0AA0 SIMATIC S7-300, Digital Output SM 322:

SIMATIC S7-300, Digital output SM 322, isolated, 32 DO, 24 V DC, 0.5A, 1x 40-pole, Total current 4 A/group (16 A/module)

The 6ES7322-1BL00-0AA0 is a digital output module from Siemens' SIMATIC S7-300 series, part of the SM 322 family. Designed for high-channel-density industrial automation, this module features 16 isolated digital output channels with 24V DC transistor outputs (sink/source configurable). It supports channel-to-channel and channel-to-backplane isolation to ensure signal integrity and reduce electromagnetic interference. The module is housed in a compact form factor (40 mm width) and connects via a 40-pin front connector, suitable for central or distributed configurations in control cabinets. It supports hot-swapping for seamless maintenance and includes diagnostic LEDs for channel status monitoring.

Technical Specifications

Product Series	SIMATIC S7-300 SM 322 Digital Output Module
Output Channels	16 digital outputs (24V DC, transistor type)
Output Type	Isolated transistor outputs (sink/source configurable)
Voltage/Current	24 V DC, 0.5 A per channel (max. 4 A per group)
Isolation	Channel-to-channel and channel-to-backplane isolation
Power Supply	24 V DC (backplane-powered)
Power Loss	3 W (typical)
Diagnostic Features	LED indicators for channel status and faults, diagnostic interrupts
Configuration	STEP 7 software for parameterization (output type, data format)
Connection	40-pin front connector, shielded cables (max. 320 m @ 125 kHz)
Environmental	-20°C to 60°C operating temperature, RoHS compliant
Physical Dimensions	40 mm (W) * 125 mm (H) * 120 mm (D), 235 g weight
Protection	IP20 rating, overcurrent and short-circuit protection
Compliance	CE, UL, and RoHS standards
Application Areas	Industrial automation, discrete manufacturing, and actuator control requiring compact, high-density digital outputs.

Packing & Delivery

100% brand New and Original Factory Seal!
Warranty: 1 year
Package: Original packing with cartons.
Delivery time: Shipped in 3-7 days after payment
All the goods will be tested before shipment.
