Name: 3WL1110-2BB34-4AN2-Z C22+F31 SIEMENS Fixed-mounted Circuit Breaker 3-pole
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 3WL1110-2BB34-4AN2-Z C22+F31
Price: 50.00 USD
Availability: InStock

Home > Products > SIEMENS PLC Module >

3WL1110-2BB34-4AN2-Z C22+F31 SIEMENS Fixed-mounted Circuit Breaker 3-pole

Siemens 3WL1110 circuit breaker 1000A

fixed-mount circuit breaker 690V

3-pole circuit breaker with warranty

Place of Origin:

GERMANY

Brand Name:

SIEMENS

Model Number:

3WL1110-2BB34-4AN2-Z C22+F31

Request A Quote

Product Details

Brand:

SIEMENS

Warranty:

1 Year

Highlight:

Siemens 3WL1110 circuit breaker 1000A

fixed-mount circuit breaker 690V

3-pole circuit breaker with warranty

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

6SL3120-1TE21-8AD0 SIEMENS S120 Single Motor Module Input

Get Best Price

6SE6420-2UD23-0BA1 SIEMENS MICROMASTER 420

Get Best Price

6ES7972-0BB12-0XA0 SIEMENS PROFIBUS DP Bus Connector

Get Best Price

6SL3162-2ME01-0AC0 SIEMENS S120 C/D Type Adapter Cable

Get Best Price

Contact Now

Product Description

SIEMENS 3WL1110-2BB34-4AN2-Z C22+F31 Fixed-mounted Circuit Breaker 3-pole

Fixed-mounted circuit breaker 3-pole, size I, IEC In=1000A to 690V, AC50/60Hz Icu=55kA at 500V frnt.conn. top/bot. dual-hole

The 3WL1110-2BB34-4AN2-Z C22+F31 is a three-pole air circuit breaker from Siemens' SENTRON 3WL series, designed for reliable low-voltage power distribution and motor protection. This module integrates advanced overcurrent protection, remote monitoring capabilities, and modular design, making it suitable for demanding industrial and commercial applications.

Technical Specifications

Product Series	SENTRON 3WL Air Circuit Breaker
Model	3WL1110-2BB34-4AN2-Z with options C22 (Ready Indicator) and F31 (auxiliary release)
Poles	3-pole configuration
Rated Current	1000A (adjustable via ETU 25B electronic trip unit)
Voltage Rating	690V AC, 50/60Hz
Short-Circuit Breaking Capacity (Icu)	55kA at 500V
Protection Functions	LSI (Long-delay, Short-delay, Instantaneous) overcurrent protection Adjustable thresholds for precise coordination
Operating Mechanism	Motorized/manual operation with spring-charging motor AC 208-240V or DC 220-250V power supply
Auxiliary Contacts	2NO+2NC (normally open/closed) for status signaling
Communication	Integrated PROFINET/PROFIBUS support (via optional modules)
Diagnostic Features	LED status indicators for module health and trip status Web server for remote configuration and monitoring Trace function for event-driven analysis
Physical Dimensions	100 mm (W) × 125 mm (H) × 75 mm (D), 0.8 kg weight
Protection Class	IP20 (front-panel protection)
Compliance	IEC 60947-2, CE, UL, RoHS standards
Environmental Resilience	Operating temperature: -25°C to +60°C Vibration/shock-resistant design
