Name: Omron R88M-G40030H-S2 400W AC Servo Motor 200VAC 3000RPM
Brand: Xiamen Online Union Technology Co., Ltd
SKU: R88M-G40030H-S2
Price: 99 USD
Availability: InStock

Home Products OMRON Parts

Omron R88M-G40030H-S2 400W AC Servo Motor 200VAC 3000RPM

Product Details:

Place of Origin:	Japan
Brand Name:	OMRON
Model Number:	R88M-G40030H-S2

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$99
Delivery Time:	In stock/1-3days
Payment Terms:	T/T
Supply Ability:	10

Contact Now

Detailed Product Description

Highlight:

Omron 400W AC servo motor

200VAC servo motor 3000RPM

Omron R88M servo motor

R88M-G40030H-S2 OMRON G-Series/SmartStep 2 AC servo motor

The Omron R88M-G40030H-S2 is a 400W AC servo motor from the G-Series, designed for high-precision industrial automation applications. It operates at 200VAC with a maximum speed of 3000 RPM, featuring an incremental encoder and key/oil seal protection. This motor is part of the SMARTSTEP2 system, known for its compact size, real-time auto-tuning, and vibration suppression capabilities. It supports high-speed positioning (500kpps pulse frequency) and includes feedback pulse monitoring for abnormal position detection.

Technical Specifications

Motor Type: AC Servo Motor
Series: OMNUC G-Series
Power Rating: 400W
Voltage Rating: 200VAC
Speed: 3000 RPM
Rated Torque: 184.1 oz-in (1300 mNm)
Max Torque (Momentary): 509.8 oz-in (3600 mNm)
Shaft Diameter: 0.575" (14.60mm)
Shaft Length & Bearing: 1.181" (30.00mm)
Mounting Hole Spacing: 2.756" (70.00mm)
Encoder Type: Incremental
Termination Style: Pre-wired cable with connector
Protection Features: Key slot, oil seal
Dimensions: Square body (60.00mm × 60.00mm)
Operating Temperature: 0°C to 40°C
Weight: 1.2 kg
Control System: SMARTSTEP2 (supports real-time auto-tuning, vibration suppression)
Pulse Frequency: 500kpps (for high-speed control)
Installation: DIN rail one-touch mounting (optional unit)
