Name: LV-S41 KEYENCE Sensor Head, Spot Reflective, Small
Brand: Xiamen Online Union Technology Co., Ltd
SKU: LV-S41
Price: 50.00 USD
Availability: InStock

Home > Products > KEYENCE Parts >

LV-S41 KEYENCE Sensor Head, Spot Reflective, Small

KEYENCE LV-S41 laser sensor

digital spot reflective sensor

KEYENCE laser sensor head

Place of Origin:

Japan

Brand Name:

KEYENCE

Model Number:

LV-S41

Request A Quote

Product Details

Highlight:

KEYENCE LV-S41 laser sensor

digital spot reflective sensor

KEYENCE laser sensor head

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

SR-X300W KEYENCE Wide Field Type KEYENCE Parts Barcode Reader Scanner IP67

Get Best Price

SR-UR1 KEYENCE IP65 USB Communication Unit For SR X Series AI Powered Code Reader

Get Best Price

SR-700HA KEYENCE Ultra Compact Fixed Type Code Reader 5VDC Water Resistant

Get Best Price

SR-700 KEYENCE Ultra Compact 1D And 2D Code Reader SR-700 Series

Get Best Price

Contact Now

Product Description

KEYENCE LV-S41 Sensor Head, Spot Reflective, Small

The Keyence LV-S41 is a compact digital laser sensor designed for high-precision detection in industrial automation. Part of the LV-S series, this model utilizes a visible red semiconductor laser (655 nm wavelength) and diffuse reflection principles to achieve accurate measurement of small targets at long distances.

Key Features

Maximum detection range of 600 mm (MEGA mode)
Small spot diameter of approximately 1.2 mm at 400 mm
Multiple response times (80 µs, 500 µs, 4 ms) for varying operational speeds
Programmable light/dark mode selection
Durable design with IP67 environmental protection
Vibration resistance (10-55 Hz, 1.5 mm double amplitude)
Wide operating temperature range (-10°C to +50°C)
Compatible with NPN/PNP output configurations
Built-in output indicator LED for status monitoring

Technical Specifications

Product Type	Digital Laser Sensor (Diffuse Reflection Type)
Detection Principle	Visible red semiconductor laser (655 nm wavelength)
Detection Range	MEGA: 600 mm ULTRA: 500 mm SUPER: 400 mm TURBO: 300 mm FINE: 200 mm HSP: 150 mm
Spot Diameter	Approximately 1.2 mm (at 400 mm detection distance)
Response Time	80 µs / 500 µs / 4 ms (selectable)
Output Type	NPN/PNP open collector, 30 VDC max, 50 mA max
Control Modes	Light/Dark programmable
Power Supply	10-30 VDC (including 10% ripple), Class 2/LPS compliant
Power Consumption	≤60 mA (24 VDC), ≤110 mA (12 VDC)
Environmental Protection	IP67 (IEC60529)
Operating Temperature	-10°C to +50°C (non-freezing)
Relative Humidity	35-85% RH (non-condensing)
Vibration Resistance	10-55 Hz, 1.5 mm double amplitude (X/Y/Z directions, 2 hours each)
Shock Resistance	1,000 m/s² (X/Y/Z directions, 6 times each)
Housing Material	Glass-reinforced plastic, polycarbonate display, acrylic lens cover
Weight	Approximately 70g
Special Features	Output indicator LED, small spot design for easy installation, FDA Class 1 laser compliance

Packing & Delivery

100% brand new and original factory seal
1 year warranty
Original packing with cartons
Shipped in 3-7 days after payment
All goods tested before shipment
