6AV2123-2JB03-0AX0 SIEMENS SIMATIC HMI KTP900 Basic

SIEMENS 6AV2123-2JB03-0AX0 SIMATIC HMI KTP900 Basic

Product Description:

The SIEMENS 6AV2123-2JB03-0AX0 is a sophisticated SIMATIC HMI (Human Machine Interface) Basic Panel designed for intuitive operator control and visualization in industrial automation environments. This 7-inch TFT display with touch screen functionality combines reliable performance with user-friendly operation, making it ideal for machine-level monitoring and control applications. As part of Siemens' comprehensive automation portfolio, this HMI panel offers seamless integration with SIMATIC controllers and other automation components.

Featuring a high-resolution color display with LED backlighting, the 6AV2123-2JB03-0AX0 delivers clear and vibrant visualization of process data, alarm messages, and operational parameters. The resistive touch screen supports multi-touch operation and provides responsive control even when operators are wearing gloves. The panel's robust design ensures reliable performance in industrial environments with protection against dust, moisture, and electromagnetic interference, complying with IP65 front panel protection when properly installed.

This HMI panel is particularly suitable for applications in manufacturing, process automation, and building management systems where reliable data visualization and operator interaction are essential. Its compact form factor makes it ideal for space-constrained installations while providing sufficient display area for effective process monitoring. The integrated software functionality allows for efficient project development and deployment, reducing engineering time and costs through pre-configured elements and templates.

Technical Specifications:

Display Characteristics: The panel features a 7-inch TFT color display with a resolution of 800 x 480 pixels (WVGA). The screen utilizes LED backlighting technology with a brightness of 250 cd/m² and a contrast ratio of 400:1. The display supports 65,536 colors and features an analog resistive touch screen with protective film. The viewing area measures 152mm x 91mm with a diagonal screen size of 7 inches.

Performance Specifications: The panel is equipped with a 32-bit RISC processor running at 400MHz, ensuring responsive operation and smooth screen updates. It provides 12MB of user memory for project data, recipes, and alarm logging. The backlight lifetime is rated for 50,000 hours at 25°C ambient temperature. The touchscreen supports simultaneous operation of multiple elements with a touch accuracy of ±1mm.

Communication Interfaces: The unit features an integrated PROFINET interface with 2-port switch functionality, supporting 10/100 Mbps auto-negotiation. The communication protocol supports 32 connections for S7 communication and 4 connections for open user communication. The interface is configured via RJ45 connectors with integrated LEDs for status indication.

Electrical Specifications: The panel operates on a 24V DC power supply with a range of 19.2V to 28.8V DC. The typical power consumption is 8W during operation, with a maximum inrush current of 2.5A. The unit includes reverse polarity protection and overload protection circuits. The leakage current is typically less than 1mA.

Environmental Specifications: The operating temperature range is 0 to 50°C, with a storage temperature range of -20 to 60°C. The relative humidity rating is 10% to 95% non-condensing. The panel is rated for operation at altitudes up to 2000 meters above sea level. The vibration resistance is 0.075mm amplitude at 5-8.4Hz and 1G acceleration at 8.4-150Hz. Shock resistance is 5G for 30ms duration.

Mechanical Specifications: The front panel protection rating is IP65 (NEMA 4/12) when properly installed, providing protection against dust and water jets. The overall dimensions are 217mm x 162mm x 46mm (W x H x D), with a cutout requirement of 200mm x 144mm. The weight is approximately 0.9kg. The housing is constructed of polycarbonate with a gray color (RAL 7032) and chemical-resistant surface.

Software and Programming: The panel is programmed using Siemens TIA Portal with WinCC Basic/Comfort software. It supports alarm management with 500 alarm buffers, recipe handling with 1000 data records, and language switching for multiple regional settings. The runtime software supports 500 tags with 5000 screen objects total.

Certifications and Standards: The panel meets CE markings, UL standards (UL 508), and cULus listings. It complies with IEC 61131-2 for programmable controllers and meets EMC standards including EN 61000-6-2 and EN 61000-6-4. The device is RoHS compliant and meets WEEE directives.

Installation Requirements: The panel is designed for front-panel mounting with four mounting clips included. The installation depth behind the panel is 35mm minimum. All connections are made through the rear interface compartment with cable glands for secure wiring. The unit supports both vertical and horizontal mounting orientations.

Functional Features: The panel includes integrated real-time clock with battery backup, supporting time-stamped alarm logging. It features 32-level password protection with configurable access rights. The device supports data logging to external storage via USB interface. The built-in Web server allows remote monitoring and diagnosis via standard web browsers.

Disclaimer: This information is provided for reference purposes only. For complete specifications and installation guidelines, consult the official Siemens documentation. Installation and operation must be performed by qualified personnel following all safety regulations. Specifications are subject to change without notice and may vary based on specific application requirements.

FAQ & Contact:

Q: Are you a trading company or a manufacturer?

A: We are a trading company.

Q: What is your lead time?

A: It usually takes one to three days if we have it in stock. If the goods are not in stock, you need to negotiate.

Q: Does your company provide samples? Is it free or do you charge extra?

A: It depends on the goods you need and the quantity you order.

Q: What are your terms of payment?

A: 100%  T/T before shipping. If the quantity is large, we can negotiate.

Our Services:

1,All our products are new and original, and of good quality.

2,Our prices are very competitive.

3,We have a large quantity in stock, so we could help the customers to get the components which are difficult to get.

4,All inquiries will be valued and will reply in 24.

Packing & Delivery:

1)100% brand New and Original Factory Seal!

2)Warranty: 1 year

3)Package: Original packing with cartons.

4)Delivery time: Shipped in 3-7 days after payment

5) All the goods will be tested before shipment.
