6ES7153-4AA01-0XB0 SIEMENS IM153-4 PN IO for 12 Modules S7-300

SIEMENS 6ES7153-4AA01-0XB0 IM153-4 PN IO for 12 Modules S7-300

Product Description:

The SIEMENS 6ES7153-4AA01-0XB0 is a high-performance distributed I/O module designed for the ET 200S PROFINET system. This innovative interface module serves as the central communication unit that connects the distributed I/O station to the PROFINET network, enabling seamless data exchange between field devices and the central automation system. The module is engineered for maximum flexibility and reliability in industrial automation applications, providing efficient integration of digital and analog signals into PROFINET-based control systems.

Featuring a compact and modular design, this interface module supports the connection of various digital and analog I/O modules, allowing for customized configuration according to specific application requirements. The robust metal housing provides excellent electromagnetic compatibility and mechanical protection, making it suitable for use in harsh industrial environments. The integrated PROFINET interface supports real-time communication and enables easy integration into existing network infrastructures.

The 6ES7153-4AA01-0XB0 is particularly valuable in applications requiring distributed control architecture, such as automotive manufacturing, packaging machinery, and material handling systems. Its diagnostic capabilities and hot-swappable module design ensure maximum system availability and reduced maintenance time. The module supports device replacement without removable media, simplifying maintenance procedures and enhancing overall system reliability.

Technical Specifications:

General Specifications: The interface module operates as part of the SIMATIC ET 200S distributed I/O system. It is designed for mounting on standard DIN rails and supports connection of up to 63 I/O modules. The module requires a 24V DC power supply with a range of 20.4V to 28.8V DC. The typical power consumption is 1.5W during operation.

Communication Performance: The module features a 2-port PROFINET interface with integrated switch functionality, supporting 10/100 Mbps auto-negotiation. It supports PROFINET IO Conformance Class B and Real-Time (RT) communication with update times as fast as 1ms. The maximum number of I/O addresses supported is 244 bytes for inputs and 244 bytes for outputs.

PROFINET Features: The interface supports MRP (Media Redundancy Protocol) for network redundancy with recovery time less than 200ms. It includes integrated web server functionality for diagnostic purposes and supports LLDP (Link Layer Discovery Protocol) for automatic network topology detection. The device replacement without removable media feature allows for easy module replacement without requiring pre-configuration.

Electrical Characteristics: The module features a rated voltage of 24V DC with reverse polarity protection. The backplane bus current capacity is 1.2A maximum for connected modules. The module includes diagnostic LEDs for power status, network activity, and system errors. All electrical connections are made through removable front connectors with screw-type terminals.

Environmental Specifications: The operating temperature range is -20°C to +60°C. The storage temperature range is -40°C to +70°C. The relative humidity rating is 5% to 95% non-condensing. The module can operate at altitudes up to 2000 meters above sea level without derating. The vibration resistance meets IEC 60068-2-6 standards with 5-8.4Hz at 3.5mm amplitude and 8.4-150Hz at 1G acceleration.

Mechanical Specifications: The module dimensions are 30mm x 126mm x 117mm (W x H x D) and it weighs approximately 200g. The housing is constructed of metal with plastic end caps. The front connector system uses 40-pin connectors for power and data transmission. The module is designed for IP20 protection when installed in a control cabinet.

Certifications and Standards: The module carries CE marking and complies with all relevant European directives. It is UL listed and cULus approved for North American markets. The device meets IEC 61131-2 standards for programmable controllers and complies with IEC 61326 for EMC requirements. The PROFINET interface conforms to IEC 61158 and IEC 61784 standards.

Diagnostic Capabilities: The module provides comprehensive diagnostic functions including module status monitoring, network diagnostics, and channel-specific error detection. The integrated web server allows remote monitoring and configuration via standard web browsers. The diagnostic information is available through the PLC program for proactive maintenance.

Configuration and Programming: The module is configured using Siemens TIA Portal software. It supports automatic detection and parameter assignment of connected I/O modules. The device name can be assigned via PROFINET using PRONETA or TIA Portal. The configuration includes parameter setting for each connected I/O module.

Safety Features: While primarily a standard I/O module, the system can be expanded with safety-related modules that meet SIL 3 according to IEC 61508. The module includes short-circuit protection and overload protection for the backplane power supply.

Application Flexibility: The interface module supports mixed configuration of standard and high-feature modules. It can be used in standalone applications or as part of a larger distributed I/O system. The module supports isochronous mode operation for motion control applications requiring precise synchronization.

Disclaimer: This information is provided for reference purposes only. For complete specifications and installation guidelines, consult the official Siemens documentation. Installation and operation must be performed by qualified personnel following all safety regulations and local electrical codes. Specifications are subject to change without notice and may vary based on specific application requirements.
