GX-OD1621 OMRON EtherCAT digital I/O unit 16 x outputs PNP 1-wire expandable

OMRON GX-OD1621 EtherCAT digital I/O unit 16 x outputs PNP 1-wire expandable

Product Description:

The OMRON GX-OD1621 is a high-density digital output module designed for the NX Series EtherCAT Automation Platform. This advanced 16-point output module provides reliable switching capability for various industrial automation applications, offering exceptional performance and flexibility in machine control systems. The module features transistor outputs with sink/source configurability, allowing for seamless integration into different control architectures without requiring additional interface components.

Engineered with OMRON's expertise in industrial automation, the GX-OD1621 incorporates intelligent diagnostics and status monitoring capabilities that enhance system reliability and simplify maintenance procedures. The module's compact design maximizes I/O density while maintaining excellent thermal characteristics, making it ideal for space-constrained control cabinets. The built-in diagnostics include output status monitoring, load voltage detection, and error detection functions that provide comprehensive system visibility.

The GX-OD1621 is particularly suitable for applications in packaging machinery, assembly systems, and material handling equipment where high-speed switching and reliable operation are essential. The module's high noise immunity and robust construction ensure stable performance in electrically noisy industrial environments. The configurable parameters and detailed diagnostics enable quick troubleshooting and reduce downtime, contributing to improved overall equipment effectiveness.

Technical Specifications:

General Specifications: The GX-OD1621 is a 16-point digital output module for the NX Series platform. The module occupies one slot in the NX bus base unit and communicates via EtherCAT fieldbus. The backplane current consumption is 70mA maximum from the 5V DC supply. The module requires no external power supply for logic circuits.

Output Characteristics: The module provides 16 transistor outputs with configurable sink/source operation. Each output point can switch up to 0.5A continuous current at 12-24V DC. The total module current capacity is 4A maximum. The residual voltage is 1.5V maximum at rated current. The response time is 1ms maximum for both ON and OFF states.

Electrical Specifications: The load voltage range is 12-24V DC ±10%. The allowable momentary voltage drop is 10ms maximum at 85% of minimum operating voltage. The inrush current is 3A maximum for 10ms. The leakage current is 0.1mA maximum when OFF. The minimum load current is 1mA for reliable operation.

Protection Features: The module includes short-circuit protection with automatic shutdown and manual reset. Overcurrent protection limits output current to prevent damage. The outputs are protected against reverse polarity and overvoltage conditions up to 30V DC. The module features thermal shutdown protection that activates at 85°C with automatic recovery.

Environmental Specifications: The operating temperature range is 0 to 55°C. The storage temperature range is -25 to 75°C. The relative humidity rating is 10% to 95% non-condensing. The module can operate at altitudes up to 2000 meters. The vibration resistance is 10 to 57Hz with 0.075mm amplitude and 57 to 150Hz with 1G acceleration. The shock resistance is 15G for 11ms duration.

Isolation and Safety: The isolation voltage is 1500V AC between field side and logic side. The module meets reinforced insulation requirements according to IEC 61010-1. The clearance and creepage distances comply with IEC 60664-1 standards for pollution degree 2 environments.

Connection System: The output connections are made through a removable 20-pin Euro-style connector. The recommended wire size is 0.3 to 1.5mm². The connector features a locking mechanism for secure connection and includes labeling space for wire identification.

Diagnostic Functions: The module provides per-point status indication through individual LED indicators. The diagnostics include output load voltage detection, short-circuit detection, and over temperature detection. Error information is available through the EtherCAT master for comprehensive system monitoring.

Configuration and Programming: The module parameters are configured using OMRON Sysmac Studio software. Configurable parameters include output test mode, error mode selection, and diagnostic enable/disable settings. The module supports online configuration changes without stopping operation.

Certifications and Standards: The module carries CE marking and complies with all applicable European directives. It is UL listed and cULus approved. The device meets IEC 61131-2 standards for programmable controllers and complies with IEC 61326 for EMC requirements.

Mechanical Specifications: The module dimensions are 30mm x 130mm x 120mm (W x H x D). The weight is approximately 200g. The front panel features status LEDs and a module identification label. The housing is constructed of flame-retardant plastic with IP20 protection rating.

Application Performance: The module supports maximum switching frequency of 100Hz for resistive loads. The electrical endurance is 100,000 operations minimum at rated load. The mechanical endurance exceeds 10 million operations. The module is suitable for controlling solenoids, relays, indicators, and other DC loads.

Compatibility: The GX-OD1621 is compatible with all NX Series CPU units and base units. The module requires Sysmac Studio version 1.09 or later for configuration. The EtherCAT communication supports distributed clock functionality for precise synchronization.

Disclaimer: This information is provided for reference purposes only. For complete specifications and installation guidelines, consult the official OMRON documentation. Installation and operation must be performed by qualified personnel following all safety regulations and local electrical codes. Specifications are subject to change without notice.
