Name: LV-H42 KEYENCE Digital Laser Sensor Long-distance
Brand: Xiamen Online Union Technology Co., Ltd
SKU: LV-H42
Price: 50.00 USD
Availability: InStock

Home > Products > KEYENCE Parts >

LV-H42 KEYENCE Digital Laser Sensor Long-distance

KEYENCE digital laser sensor

long-distance laser sensor

KEYENCE LV-H42 sensor

Place of Origin:

Japan

Brand Name:

KEYENCE

Model Number:

LV-H42

Request A Quote

Product Details

Model:

LV-H42

Type:

Long-distance Area

FDA (CDRH) Part 1040.10:

Class II

Light Source:

Visible Red Semiconductor Laser

Wavelength:

660 Nm

FINE:

250 Mm

TURBO:

500 Mm

SUPER:

1000 Mm

Ambient Temperature:

-10 To +55 °C (No Condensation)

Relative Humidity:

35 To 85 % RH (No Condensation)

Case:

Glass Reinforced Plastic

Lens Cover:

Polyarylate

Weight:

Approx. 45 G

Highlight:

KEYENCE digital laser sensor

long-distance laser sensor

KEYENCE LV-H42 sensor

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

SR-X300W KEYENCE Wide Field Type KEYENCE Parts Barcode Reader Scanner IP67

Get Best Price

SR-UR1 KEYENCE IP65 USB Communication Unit For SR X Series AI Powered Code Reader

Get Best Price

SR-700HA KEYENCE Ultra Compact Fixed Type Code Reader 5VDC Water Resistant

Get Best Price

SR-700 KEYENCE Ultra Compact 1D And 2D Code Reader SR-700 Series

Get Best Price

Contact Now

Product Description

LV-H42 KEYENCE Digital Laser Sensor Long-distance

The KEYENCE LV-H42 is a high-performance digital laser sensor designed for long-distance detection and precise measurement in various industrial applications. It belongs to the LV series, known for its compact size, powerful functionality, and ability to generate strong, focused laser beams over extended distances. This sensor is particularly suitable for applications that require stable detection of various shaped objects, even at significant distances from the sensor head.

Technical Specifications

Type	Long-distance area detection laser sensor
Light Source	Visible red semiconductor laser with a wavelength of 660nm
Detection Distance	FINE mode: 250mm TURBO mode: 500mm SUPER mode: 1000mm
Detection Range	Adjustable, with a typical detection region width that can be modified using optional accessories like the LV-102 shutter
Output Configuration	Supports both NPN and PNP output types
Response Time	Selectable, ranging from fast to slow
Environmental Adaptability	Operating temperature range: -10°C to +55°C (no freezing) Relative humidity: 35% to 85%RH (no condensation) Enclosure Rating: IP67
Power Supply	12-24VDC ±10%, with a consumption current of 35mA or less (excluding load)
