Name: 6ES7155-6AU01-0CN0 SIEMENS SIMATIC ET 200SP, PROFINET, 2-port Interface Module
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 6ES7155-6AU01-0CN0
Price: 50.00 USD
Availability: InStock

Home > Products > SIEMENS PLC Module >

6ES7155-6AU01-0CN0 SIEMENS SIMATIC ET 200SP, PROFINET, 2-port Interface Module

SIEMENS SIMATIC ET 200SP interface module

PROFINET 2-port PLC module

SIEMENS ET 200SP with warranty

Place of Origin:

GERMANY

Brand Name:

SIEMENS

Model Number:

6ES7155-6AU01-0CN0

Request A Quote

Product Details

Brand:

SIEMENS

Warranty:

1 Year

Highlight:

SIEMENS SIMATIC ET 200SP interface module

PROFINET 2-port PLC module

SIEMENS ET 200SP with warranty

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

6SL3120-1TE21-8AD0 SIEMENS S120 Single Motor Module Input

Get Best Price

6SE6420-2UD23-0BA1 SIEMENS MICROMASTER 420

Get Best Price

6ES7972-0BB12-0XA0 SIEMENS PROFIBUS DP Bus Connector

Get Best Price

6SL3162-2ME01-0AC0 SIEMENS S120 C/D Type Adapter Cable

Get Best Price

Contact Now

Product Description

6ES7155-6AU01-0CN0 SIEMENS SIMATIC ET 200SP, PROFINET, 2-port Interface Module

SIEMENS 6ES7155-6AU01-0CN0 SIMATIC ET 200SP, PROFINET, 2-port Interface Module:

SIMATIC ET 200SP, PROFINET, 2-port interface module IM 155-6PN/2 High Feature, 1 slot for BusAdapter, max. 64 I/O modules and 16 ET 200AL modules, S2 redundancy, multi-hotswap, 0.25 ms, isochronous mode, optional PN strain relief, including server module.

Technical Specifications

General Information

Product Type: IM 155-6 PN/2 High Feature Interface Module
Manufacturer Series: SIMATIC ET 200SP
Hardware Functional State: FS02 or higher
Firmware Version: V4.2 (and is updateable)

Communication and Interface

Primary Interface: PROFINET IO
Number of PROFINET Interfaces: 1 interface with 2 ports (integrated switch)
Bus Adapter: Has 1 slot for a SIMATIC Bus Adapter, allowing flexibility in the physical connection type (copper or fiber optic)
Configuration: Can be configured with STEP 7 (TIA Portal) as of version V15.1 or via GSD file

System Expansion

Max. Number of ET 200SP I/O Modules: 64 modules
Max. Number of ET 200AL Modules: 16 modules
Max. Address Space per Module: 288 bytes each for input and output data
Max. Address Space per Station: 1,440 bytes

Electrical Data

Rated Supply Voltage (DC): 24 V DC
Permitted Voltage Range: 19.2 V to 28.8 V DC
Reverse Polarity Protection: Yes
Power Failure Bridging Time: 10 ms
Max. Current Consumption: 700 mA
Typ. Power Loss: 2.4 W

Key Features and Functions

Module Replacement During Operation (Hot Swapping): Yes, for multiple modules
Redundancy: Supports system redundancy (S2 redundancy)
Isochronous Mode: Yes, with a data transfer time as low as 0.25 ms
I&M Data: Supports I&M0 to I&M3 for extensive identification and maintenance data
Clock Synchronization: Supported
Diagnostic LEDs: Includes RUN, ERROR, MAINT, PWR-LED, and LINK TX/RX LEDs for clear status indication

Physical Data

Dimensions (W x H x D): Approximately 50 x 117 x 74 mm
Weight: Approximately 170-182 grams

Environmental Conditions

Max. Operating Temperature:
- +50 °C for vertical installation
- +60 °C for horizontal installation
Max. Installation Altitude: 5,000 meters

Packing & Delivery

100% brand New and Original Factory Seal!
Warranty: 1 year
Package: Original packing with cartons
Delivery time: Shipped in 3-7 days after payment
All the goods will be tested before shipment
