Name: 1756-OB32 Allen Bradley ControlLogix Digital Output Module
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 1756-OB32
Price: 50.00 USD
Availability: InStock

Home > Products > Allen Bradley PLC >

1756-OB32 Allen Bradley ControlLogix Digital Output Module

Allen Bradley ControlLogix output module

1756-OB32 digital output module

PLC digital output module with warranty

Place of Origin:

USA

Brand Name:

Allen Bradley

Model Number:

1756-OB32

Request A Quote

Product Details

Module Type:

Sourcing (current Flows Out Of The Module)

Voltage Range:

10–31V DC (nominal 24V DC)

Current Capacity:

0.5A Per Point (max 4A Total For The Module)

Isolation:

500V AC For 1 Second (channel-to-backplane)

Response Time:

≤1ms Turn-on, ≤3ms Turn-off

Power Consumption:

300mA @5V, 2.5mA @24V (1.58W Typical)

Terminal Block:

1756-TBCH (cage Clamp) Or 1756-TBS6H (spring Clamp)

Software:

Configured Via RSLogix 5000 Or Studio 5000 Logix Designer

Highlight:

Allen Bradley ControlLogix output module

1756-OB32 digital output module

PLC digital output module with warranty

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

MPL-B320P-MJ74AA Allen Bradley Low Inertia AC Servo Motor

Get Best Price

2198-D057-ERS3 Allen Bradley Kinetix 5700 Dual Axis Servo Drive

Get Best Price

2198-D020-ERS3 Allen Bradley Kinetix 5700 Dual Axis Servo Drive

Get Best Price

1794-IA16 Allen Bradley Flex I/O AC Input Module

Get Best Price

Contact Now

Product Description

1756-OB32 Allen Bradley ControlLogix Digital Output Module

The Allen-Bradley 1756-OB32 is a high-reliability digital output module in the ControlLogix series, designed for industrial automation systems requiring precise control of external devices. It provides 32 isolated digital output points with a 10-31V DC operating range, enabling seamless integration with ControlLogix controllers and compatibility across diverse industrial applications.

Key Features

High-Capacity Output

32 Digital Outputs: Each channel supports independent configuration and force functions, allowing flexible control of devices like indicators, relays, contactors, solenoid valves, buzzers, and alarms.
Robust Drive Capability: Directly drives loads such as 24V DC relays, contactors, and solenoid valves, with each channel handling up to 0.5A (module total ≤4A).

Visual Monitoring & Diagnostics

32 LED Indicators: Green LEDs per channel provide real-time status feedback (on/off), enabling quick fault identification and operational verification.

Modular Design & Installation

Single-Slot Footprint: Occupies one slot in a ControlLogix chassis, optimizing space in compact systems.
Removable Terminal Block (RTB): Uses 1756-TBCH (cage clamp) or 1756-TBS6H (spring clamp) for tool-free wiring, reducing maintenance time.

System Integration

Producer/Consumer Technology: Leverages ControlLogix architecture for efficient data sharing with other controllers, enhancing system-wide coordination.
Universal Compatibility: Works with all ControlLogix processors (e.g., 1756-L71, 1756-L72) and supports hot-swap under power (RIUP) for minimal downtime.

Applications

The 1756-OB32 is ideal for:

Industrial Automation: Controlling conveyor systems, packaging machinery, and assembly lines.
Process Industries: Managing valves, pumps, and actuators in oil/gas, water treatment, and power generation.
Machine Control: Driving relays, indicators, and solenoids in CNC machines and robotic systems.

Configuration & Maintenance

Wiring: Connect field devices to RTB terminals (COM terminals grouped in 16-point pairs for shared power).
Software Setup: Define the module in RSLogix 5000/Studio 5000, assign I/O addresses, and configure channel parameters (e.g., output force, fault handling).
Maintenance: Replace modules under power using RIUP (Removal/Insertion Under Power) to avoid system shutdowns.
