Name: 1769-PA2 Allen Bradley CompactLogix Power Supply Module
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 1769-PA2
Price: 50.00 USD
Availability: InStock

Home > Products > Allen Bradley PLC >

1769-PA2 Allen Bradley CompactLogix Power Supply Module

Allen Bradley CompactLogix power supply module

1769-PA2 PLC power supply

CompactLogix power supply with warranty

Place of Origin:

USA

Brand Name:

Allen Bradley

Model Number:

1769-PA2

Request A Quote

Product Details

Input Voltage:

85–264V AC (47–63Hz), Selectable 120V/240V Via Jumpers

Output Voltage:

24V DC (nominal)

Output Current:

2.0A Max (continuous)

Output Power:

48W (24V × 2.0A)

Efficiency:

>75% (typical)

Protection:

Overcurrent, Overvoltage, Short-circuit

Installation:

DIN Rail (35mm)

Operating Temperature:

0–60°C (32–140°F)

Highlight:

Allen Bradley CompactLogix power supply module

1769-PA2 PLC power supply

CompactLogix power supply with warranty

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

MPL-B320P-MJ74AA Allen Bradley Low Inertia AC Servo Motor

Get Best Price

2198-D057-ERS3 Allen Bradley Kinetix 5700 Dual Axis Servo Drive

Get Best Price

2198-D020-ERS3 Allen Bradley Kinetix 5700 Dual Axis Servo Drive

Get Best Price

1794-IA16 Allen Bradley Flex I/O AC Input Module

Get Best Price

Contact Now

Product Description

1769-PA2 Allen Bradley CompactLogix Power Supply Module

The Allen-Bradley 1769-PA2 is a compact, high-efficiency power supply module designed for the CompactLogix 1769 series of programmable logic controllers (PLCs). It converts 120/240V AC input power to 24V DC output, providing reliable energy for CompactLogix controllers (e.g., 1769-L23, L31, L35E) and their connected I/O expansion modules. As a critical component of the Compact I/O system, it ensures stable operation in industrial automation applications such as packaging machinery, pump stations, and material handling systems.

Key Features

Flexible Power Input

Wide Voltage Range: Supports 85-264V AC input (47-63Hz), compatible with global power standards
Dual Voltage Selection: Internal jumpers allow switching between 120V AC and 240V AC inputs, adapting to regional grid requirements

Stable DC Output

24V DC Supply: Delivers a nominal 24V DC output with a maximum current of 2.0A (48W power), sufficient for powering controllers and up to 16 local I/O modules
High Efficiency: Typical efficiency exceeds 75%, minimizing energy waste and heat generation

Robust Protection & Reliability

Comprehensive Safeguards: Built-in overcurrent (OCP), overvoltage (OVP), and short-circuit protection automatically shut down the module during faults, protecting downstream devices
Industrial Durability: Designed for harsh environments, with an operating temperature range of 0-60°C (32-140°F) and IP20 rating (requires enclosure use)

User-Friendly Design

Status Indicators: Green "POWER" LED confirms normal operation; red "FAULT" LED alerts to abnormalities (e.g., overloads, overheating)
DIN Rail Installation: Mounts easily on standard 35mm DIN rails, saving control cabinet space
Tool-Free Wiring: Screw terminal blocks for quick AC input and DC output connections
