Name: CDQMB16-10 SMC CQM Series Compact Guided Rod Cylinder
Brand: Xiamen Online Union Technology Co., Ltd
SKU: CDQMB16-10
Price: 50.00 USD
Availability: InStock

Home > Products > SMC Parts >

CDQMB16-10 SMC CQM Series Compact Guided Rod Cylinder

SMC CQM compact guided rod cylinder

SMC guided rod cylinder with warranty

compact guided rod cylinder SMC

Place of Origin:

JAPAN

Brand Name:

SMC

Model Number:

CDQMB16-10

Request A Quote

Product Details

Product Series:

CQM Series (Compact Guided Rod)

Action Type:

Double-Acting (Air Extend / Air Retract)

Bore Diameter (Ø):

16 Mm

Stroke Length:

10 Mm

Operating Pressure:

0.1 ~ 1.0 MPa (14.5 ~ 145 Psi)

Max Proof Pressure:

1.5 MPa

Buffer Type:

Rubber Bumper (Standard)

Port Size:

M5 X 0.8

Highlight:

SMC CQM compact guided rod cylinder

SMC guided rod cylinder with warranty

compact guided rod cylinder SMC

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

CDQMB16-10 SMC CQM Series Compact Guided Rod Cylinder

Get Best Price

ZK2A15K5RW-06 SMC Zm Nozzle Size 1.5, ZM VACUUM SYSTEM

Get Best Price

ZHP8OBMUA-15C6S SMC Industrial-grade 5-port Solenoid Valve

Get Best Price

ISE40A-01-T-X501 SMC Switch, ISE40/50/60 PRESSURE SWITCH

Get Best Price

Contact Now

Product Description

CDQMB16-10 SMC CQM Series Compact Guided Rod Cylinder

The SMC CDQMB16-10 is a high-precision Compact Guided Rod Cylinder from SMC's renowned CQM Series. Designed for applications requiring high rigidity and precise linear motion in a space-saving package, this unit integrates a cylinder and a guide rod mechanism into a single, compact body. The "CDQMB" series is specifically engineered to handle moments and side loads effectively, making it ideal for compact automation equipment where standard cylinders might suffer from rod deflection.

With a bore size of 16mm and a stroke of 10mm, this model is a staple in small-scale automation, electronic assembly, and light-duty positioning systems. It offers a robust solution for applications needing high accuracy and smooth operation within a minimal footprint.

Key Features & Benefits

Integrated Guide Mechanism: Features a built-in guide rod that provides high rigidity against moment loads and side thrusts, ensuring smooth and precise linear motion without rod wobble
Ultra-Compact Design: The space-saving dimensions (41.5 x 29 x 29mm) allow for dense installation in tight machinery spaces, significantly reducing the overall equipment size
Double-Acting Operation: Provides powered motion in both the extend and retract directions, offering full control over the work cycle
Rubber Buffer: Equipped with standard rubber bumpers at both ends of the stroke to absorb impact energy, reducing noise and mechanical shock at high speeds or end-of-stroke positions
Wide Operating Temperature: Capable of operating reliably in environments ranging from -10°C to +70°C (non-freezing), suitable for most industrial factory floors
Easy Mounting: The fixed mounting style allows for flexible installation in various orientations using standard mounting brackets or foot mounts

Technical Specifications

Parameter	Specification
Product Series	CQM Series (Compact Guided Rod)
Model Number	CDQMB16-10
Action Type	Double-Acting (Air extend / Air retract)
Bore Diameter (Ø)	16 mm
Stroke Length	10 mm
Operating Pressure	0.1 ~ 1.0 MPa (14.5 ~ 145 psi)
Max Proof Pressure	1.5 MPa
Buffer Type	Rubber Bumper (Standard)
Port Size	M5 x 0.8
Dimensions (W x H x D)	41.5 mm x 29 mm x 29 mm
Weight	Approx. 67 g (0.15 lbs)
Piston Rod	Threaded (External thread, typically M4 or M5 depending on variant)
Lubrication	Pre-lubricated (Grease packed)
Magnetic Switch	Not included (Requires external sensor bracket for D-M9 series sensors)
Theoretical Force (1 MPa)	~201 N (Extend) / ~176 N (Retract)

Typical Applications

Electronics Manufacturing: PCB handling, chip mounting, and wire bonding machines
Packaging Machinery: Labeling heads, small part ejection, and sealing jaws
Medical Devices: Precision dosing pumps and analyzer sample handling
Small Assembly Lines: Pick-and-place units, part sorting, and fixture clamping
Textile Machinery: Thread guides and tension control actuators

System Integration

Air Supply: Requires clean, dry compressed air (filtered to 5µm or better) with lubrication unless using a pre-lubricated version
Valves: Typically controlled by 5/2 or 3/2 solenoid valves (e.g., SMC SY3000 or VQZ series)
Sensors: Magnetic sensors (e.g., SMC D-M9N/D-M9P) can be mounted on the groove of the cylinder tube to detect piston position
Fittings: Use push-in fittings (e.g., SMC KQ2 series) with 4mm or 6mm tubing for the M5 ports

Ordering Information

Manufacturer: SMC Corporation
Product Family: CQM Compact Cylinders
MPN: CDQMB16-10
Packaging: Standard factory carton or blister pack
