Name: 6ES7231-4HF32-0XB0 Siemens SIMATIC S7-1200 Analog Input Module
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 6ES7231-4HF32-0XB0
Price: 50.00 USD
Availability: InStock

Home > Products > SIEMENS PLC Module >

6ES7231-4HF32-0XB0 Siemens SIMATIC S7-1200 Analog Input Module

Siemens S7-1200 analog input module

SIMATIC S7-1200 PLC module

6ES7231-4HF32-0XB0 analog input

Place of Origin:

GERMANY

Brand Name:

SIEMENS

Model Number:

6ES7231-4HF32-0XB0

Request A Quote

Product Details

Product Series:

SIMATIC S7-1200

Module Type:

Analog Input (AI)

Number Of Channels:

8 (Single-ended Or Differential)

ADC Resolution:

25-bit (Sigma-Delta) / 16-bit Effective

Input Types:

Voltage, Current, RTD, Thermocouple (Software Selectable)

Voltage Range:

±10 V, ±5 V, ±2.5 V, 0–10 V

Current Range:

0–20 MA, 4–20 MA

Temperature Sensors:

RTD (Pt100/1000, Ni100/1000), TC (J, K, T, E, R, S, B, N)

Highlight:

Siemens S7-1200 analog input module

SIMATIC S7-1200 PLC module

6ES7231-4HF32-0XB0 analog input

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

6ES7414-2XL07-0AB0 Siemens SIMATIC S7-400 CPU 414-2 Central Processing Unit

Get Best Price

6ES7318-3EL01-0AB0 Siemens SIMATIC S7-300 CPU 319-3 PN/DP

Get Best Price

6ES7231-4HF32-0XB0 Siemens SIMATIC S7-1200 Analog Input Module

Get Best Price

6AU1445-2AD00-0AA0 Siemens SIMOTION D445-2 DP/PN Motion Controller

Get Best Price

Contact Now

Product Description

Siemens SIMATIC S7-1200 Analog Input Module

The Siemens 6ES7231-4HF32-0XB0 is a high-precision 8-channel Analog Input Module for the SIMATIC S7-1200 series, designed as an expansion module for compact and scalable automation solutions. This high-end configuration offers superior resolution and flexibility, supporting voltage, current, resistance (RTD), and temperature (Thermocouple) signals directly without external signal conditioners.

Key Features & Benefits

Ultra-High Precision Acquisition

25-bit Sigma-Delta ADC delivers exceptional measurement precision (±0.1% of full scale typical)
Up to 16-bit + sign bit effective resolution for fine signal granularity
Fast sampling capability: scans all 8 channels in as little as 250 µs

Universal Signal Compatibility

Software-configurable inputs for voltage, current, or temperature sensors
Voltage ranges: ±10V, ±5V, ±2.5V, 0-10V
Current ranges: 0-20mA, 4-20mA (with open-circuit detection)
RTD support: Pt100, Pt200, Pt500, Pt1000, Ni100, Ni1000 (2/3-wire)
Thermocouple support: Type J, K, T, E, R, S, B, N with integrated cold junction compensation

Robustness & Reliability

Galvanic isolation: 500 VDC channel-to-channel and channel-to-backplane
Overvoltage protection up to ±35 V DC
Conformal coating protects against dust, moisture, and corrosive gases

Advanced Diagnostics & Usability

Channel-level diagnostics for wire breaks, short circuits, and out-of-range values
LED status indicators for RUN and ERROR conditions
Seamless integration with S7-1200 CPU via expansion bus

Technical Specifications

Parameter	Specification
Model Number	6ES7231-4HF32-0XB0
Product Series	SIMATIC S7-1200
Module Type	Analog Input (AI)
Number of Channels	8 (Single-ended or Differential)
ADC Resolution	25-bit (Sigma-Delta) / 16-bit effective
Input Types	Voltage, Current, RTD, Thermocouple (Software Selectable)
Voltage Range	±10 V, ±5 V, ±2.5 V, 0-10 V
Current Range	0-20 mA, 4-20 mA
Temperature Sensors	RTD (Pt100/1000, Ni100/1000), TC (J, K, T, E, R, S, B, N)
Accuracy	±0.1% of Full Scale (Typical)
Isolation	500 VDC (Channel-to-Channel, Channel-to-Backplane)
Sampling Rate	Up to 4 kHz (per channel) / 250 µs cycle time (all channels)
Power Supply	24 V DC (via backplane bus from CPU)
Power Consumption	Approx. 1.8 W (from 5V bus)
Dimensions (H x W x D)	100 mm x 45 mm x 75 mm
Operating Temperature	0°C to 60°C (32°F to 140°F)
Protection Rating	IP20 / NEMA 1 (Type 1)
Certifications	UL, cUL, CE, C-Tick, CCC, ATEX (Zone 2), IECEx

Typical Applications

Process Control: Temperature, pressure, flow, and liquid level monitoring in chemical reactors

HVAC Systems: Precise temperature control in air handling units and chillers

Water/Wastewater Treatment: pH monitoring, flow rate measurement, and pressure control

Pharmaceutical & Food & Beverage: Batch process control and sterilization monitoring

Energy Management: Power parameter acquisition in substations

Machine Building: Multi-point temperature monitoring for industrial equipment
