140DAO84000 Schneider Relay Module
140DAO84000 is a high-performance digital output module launched by Schneider Electric, belonging to the Modicon Quantum automation platform, designed specifically for industrial automation. It has 16 isolated output channels, supports AC voltage output from 20 to 253 volts, and has a maximum load current of 4A RMS (four continuous outputs). The response time is less than 1 millisecond, the switching time is less than 0.5 milliseconds, and the power consumption is only 1.85 watts. It is equipped with an internal RC filter and a 5A fuse. It is designed in a compact size of 100 x 100 x 50 millimeters, weighs 0.5 kilograms, and has a working temperature range of -25 ° C to+70 ° C, It has high reliability, fast response, and multiple protection functions (such as undervoltage protection and wire breakage protection), excellent shock and vibration resistance, and is suitable for applications where mechanical equipment frequently moves and vibrates. It is widely used in automated production lines, robot control, chemical process control, power system automation, water treatment plant automation, and building HVAC control. It can accurately control the on/off status of equipment such as motors, solenoid valves, and indicator lights.
Technical specifcations for 140DAO84000
Brand and Model Schneider 140DAO84000
Product type: Digital output module, belonging to Modicon Quantum automation platform
16 isolated output channels
Output type: Insulated (isolated) output
The output voltage range is 20 to 253 volts AC (some information mentions 24 to 230VAC, the specific range may vary depending on the product version or configuration)
Maximum load current 4A RMS (with four consecutive outputs)
Response time less than 1 millisecond
Switching time less than 0.5 milliseconds
Power consumption 1.85 watts
Protection type: Internal RC filter, providing undervoltage protection and disconnection protection, etc
Fuse rated value 5A
Size 100 x 100 x 50 millimeters
Weight 0.5 kg
Working temperature range -25 ° C to+70 ° C (some information mentions 0 ° C to 60 ° C, specific range may vary depending on product version or configuration)
Installation method: 35mm DIN rail installation
Protection level IP30 (some information is not mentioned, but industrial modules usually have a certain level of protection)
The communication interface communicates with Modicon Quantum PLC through the backplane (specific communication protocol may vary depending on system configuration)
