140CRP31200 Schneider Relay Module
140CRP31200 is a Quantum series Ethernet RIO (Remote I/O) master station module launched by Schneider Electric, designed specifically for industrial automation control systems. It has 4 Ethernet ports and supports Ethernet IP/Modbus TCP protocol, enabling efficient communication between PLC and remote I/O devices as well as distributed I/O devices. It provides core functions such as I/O scanning, link topology management, remote device configuration and diagnosis, and supports hot standby function to ensure that the IP address remains unchanged when switching between the main and backup modules, ensuring system continuity. It adopts a daisy chain loop topology structure, supports RSTP protocol, achieves communication interruption recovery within 50 milliseconds, is compatible with multiple industrial protocols, and has port mirroring Practical functions such as Service port diagnosis have passed international certifications such as UL 508, CE, C-tick, CSA C22.2 42, EN 55011, IEC 61000-4-16, and are suitable for industrial automation scenarios that require high reliability, real-time performance, and scalability, such as steel plants, cement plants, power and water treatment, etc.
Technical specifcations for 140CRP31200
Product series and types:
Product Series: Modicon Quantum
Product type: Ethernet remote I/O interface and control module (main station module)
Communication protocol and port:
Communication Protocol: Supports multiple communication protocols such as Modbus TCP/IP, Ethernet/IP, etc
Number of ports: 4 network ports (ETH1 to ETH4), with ETH3 and ETH4 commonly used for connecting primary and backup PLCs
Service port: Provides diagnosis of Ethernet ports and access to external tools and devices (such as HMI, Unity Pro, etc.)
INTERLINK port: provides connections to other Quantum EIO modules
Function and Features:
Provide I/O scanning services for remote I/O devices on remote I/O networks or device networks
Supports RSTP protocol and can recover from communication interruptions within 50 milliseconds
Support hot backup function, IP address remains unchanged when switching between primary and backup modules
Provide port mirroring function for easy monitoring and analysis of port traffic
Electrical and environmental parameters:
Power supply: 24V DC
Working temperature range: -20 ℃ to 60 ℃
Data transmission rate: 10/100 Mbps
Installation and configuration:
Only one 140CRP31200 module can be configured on the local rack
Provide RS-485 communication interface to expand the number of Modbus slaves
Support remote firmware updates for easy maintenance
Indicator lights and status:
Multiple LED indicator lights used to display module status, network communication status, etc
The indicator light can quickly determine the working status and fault situation of the module
Application areas:
Widely used in fields such as industrial automation, power systems, petrochemicals, transportation, and building control
Suitable for scenarios such as remote control systems for production lines, power monitoring systems, petrochemical production monitoring systems, traffic control systems, and building control systems
