TSXP57203M Schneider Relay Module
TSXP57203M is a Premium series PLC processor launched by Schneider Electric, which has high performance and reliability, adopts modular design, and supports control room installation. Its Boolean instruction execution time is only 37ns, and its numerical instruction execution time is only 45ns. Equipped with a main processor and co processor architecture, it can efficiently handle program operations and communication tasks. The processor is equipped with a 12Mbps backplane bus and Ethernet interface, supporting standard industrial Ethernet protocols such as Modbus TCP/IP, with a communication rate of not less than 100Mbps, and integrating real-time clock, sufficient registers, and a multilingual programming environment. It is compatible with IEC61131-3 standard and supports multiple programming methods such as LD/FBD/ST/SFC/IL, providing up to 7MB of CPU memory expansion space to ensure sufficient program space. In addition, its SOE accuracy is strictly controlled within 5ms, supporting hot standby redundancy technology, which can achieve real-time, deterministic, and high availability of industrial control systems in complex environments. It is suitable for industrial automation scenarios that require high control speed and stability.
Technical specifcations for TSXP57203M
Brand and Model: Produced by Schneider Electric, model TSXP57203M, belongs to the Premium series PLC processor.
Processing performance:
The execution time of Boolean instructions is only 37ns, and the execution time of numerical instructions is only 45ns, demonstrating excellent processing speed.
The maximum bit instruction execution time of the CPU can reach 0.037us, further ensuring the efficient performance of the processor.
Communication ability:
The communication rate of the backplane bus is a constant 12Mbps, which does not attenuate with the increase of rack and communication distance, ensuring the real-time and deterministic performance of the system.
Supports standard industrial Ethernet protocols such as Modbus TCP/IP, with a communication rate of no less than 100Mbps, facilitating high-speed communication with various devices.
Ethernet supports IO scanning mode, which can automatically identify various devices on the Ethernet network, making it convenient for users to add or remove devices in real-time online and easy to maintain.
Memory and Storage:
The CPU memory can be expanded to 7MB, providing ample available program space to meet the needs of complex control logic.
Functional features:
The CPU has a built-in real-time clock that can provide time labels for all information, facilitating time management and event recording.
The CPU has ample registers to choose from, providing flexible data processing capabilities.
The CPU module integrates multiple processors, with the main processor handling program operations and the co processor handling communication, ensuring high system availability.
The SOE accuracy is strictly guaranteed to be within 5ms, ensuring that the cause of the fault can be accurately and timely identified when it occurs.
Programming and software support:
The PLC programming software complies with the IEC61131-3 standard and provides programming languages such as LD (ladder diagram), FBD (function block diagram), ST (structured text), SFC (sequential function diagram), IL (instruction list), etc. to achieve offline simulation functionality.
The new Unity software combines the advantages of Concept and PL7, with a user-friendly interface and powerful features. It provides an integrated PLC simulator that can be debugged without hardware, improving productivity.
Physical specifications:
The net depth/length of the product is 135mm, the net weight of the product is 2.3kg, the specifications are 26 * 33 * 37 (units may be centimeters or other, please refer to the product manual for details), the shape is square, and the color is standard color.
Power supply and environmental adaptability:
The working voltage is 220V, and the system environment is at room temperature, suitable for general industrial environments.
