TSXDEZ08A5 Schneider Relay Module
TSXDEZ08A5 is a Micro series discrete input module launched by Schneider Electric. It adopts a half height format design and supports flexible wiring through screw terminal blocks. This module has the ability to input AC voltage ranging from 200 to 240V, and can adapt to various industrial power environments. The input function can be customized through configuration software, and the first four inputs can be configured as discrete inputs, latch inputs, event triggered inputs, or up/down counter inputs to meet complex logic control requirements. The module integrates a locking mechanism and a detachable screw terminal block, which ensures installation stability and is easy to maintain. The terminal block is equipped with a protective cover to fix the label, improving operational safety. This product is suitable for signal acquisition and control in industrial automation scenarios, and with its high adaptability and functional scalability, it has become a reliable component for building automation systems.
Technical specifcations for TSXDEZ08A5
Brand and Model: The brand is Schneider and the model is TSXDEZ08A5.
Input voltage: This product supports AC input of 200-240V, belonging to the half height format, and is connected through screw terminal blocks.
I/O allocation: By configuring software, specific functions can be assigned to specific inputs. The first four inputs of the discrete I/O module on the first slot of the TSX Micro PLC can be configured as discrete input, latch input, event triggered input, or up/down counter input.
Latch input: including inputs% I1.0 to% I1.3. For pulses shorter than the PLC scanning cycle, their storage and processing are transferred to the next PLC scanning cycle. When there is a transition in the input state, a pulse is detected (which can be a rising and/or falling edge depending on the selected configuration).
Event triggered inputs: including inputs% I1.0 to% I1.3. When a command event occurs, the application is directly directed to the event handling process related to the input that triggered the event. Detect pulses when there is a transition in input state (depending on the selected configuration, they can be rising and/or falling edges).
Up/down counter input: including inputs from% I1.0 to% I1.3. According to the specific software configuration, up to 2 up/down counter channels can be created on these inputs, and each channel can independently complete functions such as up/down counting, bidirectional counting (with or without direction recognition), etc.
Run/Stop Command: The input% I1.8 can be set to control the PLC's RUN/STOP command, which is used to control the rising edge. The stop command on the input has higher priority than the run command sent from the terminal or network.
Program and data backup input: Input% I1.9 can be set on the rising edge to backup the application program in the flash EPROM (in internal RAM) and up to 1000 words of% Mwi.
Alarm output: On the PLC body unit, output% Q2.0 can be configured to achieve alarm function. When the PLC is in operation and no errors are detected, the alarm output status is 1, which can be used for external safety circuits of the PLC, such as controlling the power output of pre actuators or TSX Micro PLC power output.
Structure and Components:
Locking mechanism: can be used to secure the module in the slot, and can only be operated after removing the terminal block.
Detachable screw terminal block: used to connect sensors and pre actuators.
The cover of the screw terminal block: It can be used to fix the label on top.
Wiring method: The screw terminal block is equipped with a cover to ensure accurate installation position and safe operation of the screw. Each terminal on the screw terminal block can be connected through bare wire, cable end wire, or wire on a closed/open tap. The capacity of each terminal is up to 2 1mm ² (AWG 17) wires with cable ends, or 1 1.5mm ² (AWG 15) wire without cable ends, or 1 open or closed 1mm ² tap (AWG 17).
