1756-0B16E high-performance fast analog combination module

1756-0B16E is a high-performance digital output module in the Allen Bradley ControlLogix series, designed specifically for industrial automation control systems, with precise control and stable operation capabilities. This module provides 16 independent output channels, supporting 24V DC voltage output with a rated current of 0.5A per channel. The total output current can reach 8A (at 60 ° C), and the output voltage range covers 10-31.2V DC, compatible with various DC load requirements. Its photoelectric isolation design effectively blocks external interference, ensuring the stability of signal transmission, while built-in electronic fuse protection prevents overload risks.

The 1756-0B16E adopts a modular design, supports hot swappable maintenance, and is easy to replace and expand quickly. The module supports EtherNet/IP communication protocol and can be seamlessly integrated into the ControlLogix control system to achieve network communication with the upper computer, HMI, and other devices. It can be configured, monitored, and diagnosed online through RSLogix 5000 software to improve system maintainability. Its response time is only 0.2 milliseconds, suitable for scenarios that require fast action, such as packaging machinery, material sorting, etc.

This module has strong adaptability to the working environment, with a working temperature range of -40 ° C to 70 ° C, a storage temperature range of -40 ° C to 85 ° C, a humidity tolerance of 5-95% (no condensation), a protection level of IP20, and can cope with harsh industrial environments. Its compact size (132 × 102 × 52mm) and lightweight design (approximately 0.3kg) make it easy to integrate into space constrained cabinets.

1756-0B16E is widely used in manufacturing, energy, transportation, water treatment and other fields, suitable for production line control, motor start stop, pump station management and other scenarios. As part of the ControlLogix ecosystem, it is compatible with series controllers (such as 1756-A4, 1756-A17) and I/O racks, supports distributed control architecture, and is a reliable, efficient, and easy to maintain output solution in industrial automation systems.

Basic functions and technical specifications:
This module provides 16 independent digital output channels, supporting DC voltage/current output, with a rated voltage of 24V DC and a rated current of 0.5A per channel. The total output current of the module can reach 8A (at 60 ° C).
The output voltage range is 10-31.2V DC, with a nominal value of 24V DC, suitable for driving various DC loads.
The module adopts a photoelectric isolation design to ensure electrical isolation from external devices, improve system safety and anti-interference ability.
Performance characteristics:
The response time is extremely short, with a typical value of 0.2 milliseconds, suitable for industrial control scenarios that require fast response.
Support hot swappable function for easy maintenance and replacement, and built-in electronic fuse protection to prevent overload damage.
Each output channel has independent turn off and turn on delay time control to ensure the accuracy of signal transmission.
Communication and compatibility:
Supports EtherNet/IP communication protocol and can be seamlessly integrated into the ControlLogix control system to achieve network communication with the upper computer, HMI, and other devices.
Compatible with multiple ControlLogix controllers (such as 1756-A4, 1756-A17, etc.) and I/O racks, supporting distributed control architecture.
Configure and monitor through RSLogix 5000 software, providing online diagnostic and status monitoring functions for easy troubleshooting and maintenance.
Mechanical and environmental adaptability:
The module structure is compact, with dimensions of 132mm × 102mm × 52mm and a weight of approximately 0.3kg, making it suitable for installation in cabinets with limited space.
The working temperature range is -40 ° C to 70 ° C, the storage temperature range is -40 ° C to 85 ° C, the humidity adaptability is 5% to 95% (no condensation), and the protection level is IP20, suitable for various harsh industrial environments.
Application scenarios:
Widely used in automation control systems in manufacturing, energy, transportation, water treatment and other industries, such as production line control, motor control, process control and other scenarios.
Suitable for industrial applications that require high reliability, fast response, and precise control, such as packaging machinery, material conveying, pump station control, etc.
Safety and reliability:
The module design complies with industrial safety standards and has multiple built-in protection mechanisms to ensure stable operation in harsh industrial environments.
Provide status indicator lights and diagnostic information for users to monitor the working status of the module in real time, detect and handle faults in a timely manner.
