Name: MR-J3-D01 MITSUBISHI Series MELSERVO-J3 Interface Unit
Brand: Xiamen Online Union Technology Co., Ltd
SKU: MR-J3-D01
Price: 50.00 USD
Availability: InStock

Home > Products > Mitsubishi Module >

MR-J3-D01 MITSUBISHI Series MELSERVO-J3 Interface Unit

Mitsubishi MELSERVO-J3 interface unit

MR-J3-D01 servo control module

MELSERVO-J3 series with warranty

Place of Origin:

Japan

Brand Name:

MITSUBISHI

Model Number:

MR-J3-D01

Request A Quote

Product Details

Compatible Amplifiers:

MR-J3 Series (A/B/T Types)

Positioning Stations:

15 (standalone) / 255 (with MR-J3-D01)

Communication Protocol:

CC-Link Ver. 1.1/2.0

Input/Output Signals:

Digital I/O For Emergency Stop, Alarm, And Control Signals

Cable Length:

10m Standard (extendable With Repeaters)

Weight:

Approx. 0.2 Kg

Highlight:

Mitsubishi MELSERVO-J3 interface unit

MR-J3-D01 servo control module

MELSERVO-J3 series with warranty

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

Q06UDVCPU Mitsubishi High Speed Module General Purpose CPU Module

Get Best Price

ZKB-0.6YN MITSUBISHI High Precision Magnetic Particle Brake DC 24V 1800 R/Min

Get Best Price

RM100C2Z-H Mitsubishi High Precision Module Low Profile Electronic Module

Get Best Price

QY81P Mitsubishi 32 Points Module Output Module Overview 24VDC

Get Best Price

Contact Now

Product Description

MR-J3-D01 MITSUBISHI Series MELSERVO-J3 Interface Unit

The MR-J3-D01 is an interface unit designed for Mitsubishi Electric's MELSERVO-J3 Series AC servo amplifiers, enhancing their functionality in industrial automation systems. As part of the J3 Series, this model integrates advanced motion control technologies, including CC-Link communication and built-in positioning capabilities, making it ideal for applications requiring high-speed, high-precision positioning and synchronization.

Key Features

Enhanced Positioning Capability

The MR-J3-D01 expands the positioning capacity of the servo amplifier
Standard Mode: Supports up to 15 stations for indexing applications
Extended Mode (with MR-J3-D01): Enables up to 255 stations, ideal for complex multi-point positioning systems (e.g., conveyor lines, robotic arms)
Utilizes pulse train input for position control, ensuring compatibility with various PLCs and motion controllers

CC-Link Communication

Built-in CC-Link (Control & Communication Link) interface, a widely used open-network protocol in industrial automation
Enables seamless integration with CC-Link master devices (e.g., PLCs, HMIs) for real-time data exchange, monitoring, and remote parameter adjustments
Reduces wiring complexity and improves system scalability

Compatibility and Flexibility

Designed to work exclusively with MR-J3 Series servo amplifiers (e.g., MR-J3-10A to MR-J3-22KA)
Supports three-phase AC 200V and single-phase AC 200V power supplies, adapting to diverse industrial environments
Optional use of MR Configurator software for parameter setting, diagnostics, and performance tuning via USB/RS-422 interfaces

Applications

The MR-J3-D01 is widely used in:

Packaging Machinery: High-speed indexing for bottle filling, labeling, and cartoning
Printing Presses: Synchronized motion control for web tension and registration
Robotic Systems: Multi-axis coordination in pick-and-place robots
CNC Machining: Precision positioning for lathes, milling machines, and grinding equipment

Safety and Compliance

Protective Functions: Overcurrent, overvoltage, overheating, and encoder error detection
Certifications: Meets global safety standards (e.g., CE, UL)
Grounding Requirements: Must be properly grounded to prevent electric shock

Installation and Operation Guidelines

Power Off Before Wiring: Disconnect power and wait 15 minutes to ensure safety
Cable Management: Use shielded cables for encoder and communication lines to minimize noise
Thermal Management: Ensure adequate ventilation around the servo amplifier
Parameter Settings: Use MR Configurator software to optimize control loops (e.g., gain, filtering)

Conclusion

The MR-J3-D01 interface unit enhances the MELSERVO-J3 Series servo amplifiers by providing advanced positioning capabilities and CC-Link network integration. Its compact design, high-speed communication, and compatibility with industrial automation standards make it a reliable choice for precision motion control applications. For modern projects, Mitsubishi recommends evaluating the MELSERVO-J4 Series, which offers extended power ranges (up to 30 kW) and enhanced debugging tools.
