Name: PFXGP4401TAD Proface 7.5-inch Modular Touchscreen HMI
Brand: Xiamen Online Union Technology Co., Ltd
SKU: PFXGP4401TAD
Price: 50.00 USD
Availability: InStock

Home > Products > Proface Module >

PFXGP4401TAD Proface 7.5-inch Modular Touchscreen HMI

Proface 7.5-inch modular HMI

Proface touchscreen HMI module

7.5-inch Proface industrial touchscreen

Place of Origin:

Japan

Brand Name:

Proface

Model Number:

PFXGP4401TAD

Request A Quote

Product Details

Highlight:

Proface 7.5-inch modular HMI

Proface touchscreen HMI module

7.5-inch Proface industrial touchscreen

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

PFXGP4601TAD PROFACE DC 24V Touch Screen HMI Proface Touch Panel

Get Best Price

Video

PFXGP4501TADW Proface 10.4 Inch Touch Screen HMI TFT LCD Display Proface GP4000 Series

Get Best Price

PFXGP4501TADC Proface TGP4000 Series 10.4 TFT Color LCD DC Power Supply

Get Best Price

PFXGP4401WADW Proface Touchscreen HMI 32MB Memory Backlit Display GP4000 Series

Get Best Price

Contact Now

Product Description

PFXGP4401TAD Proface 7.5-inch Modular Touchscreen HMI

The PROFACE PFXGP4401TAD is a 7.5-inch TFT true-color LCD programmable human-machine interface (HMI) designed for industrial automation applications. It features a high-resolution display, intuitive touchscreen operation, and robust connectivity options, making it suitable for monitoring and controlling machinery in sectors such as manufacturing, logistics, and energy.

Technical Specifications

Display
Type	TFT true-color LCD with LED backlight (non-replaceable by users; contact Proface for replacement)
Size	7.5 inches (diagonal)
Resolution	640 × 480 pixels (VGA)
Color Depth	65,536 colors (non-flicker) / 16,384 colors (with flicker)
Brightness	Adjustable via touch panel or software (16 levels)
Backlight Lifespan	50,000+ hours (at 25°C, brightness reduced to 50% or flicker onset)
Touch Panel
Type	Resistive (analog)
Resolution	1,024 × 1,024
Durability	Rated for 1,000,000+ operations
Languages & Fonts
Supported Languages	Japanese (JIS X 0201/0208), ANK (downloadable Korean, Simplified/Traditional Chinese)
Font Sizes	Standard (8×8, 8×16, 16×16, 32×32 pixels), vector (6-127 pixels), and image fonts (8-72 pixels)
Environmental Resistance
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	10-90% RH (non-condensing, wet-bulb temperature ≤39°C)
Protection	IP65F (front panel), NEMA Type 4X/13
Vibration/Shock Resistance	Meets IEC/EN61131-2 standards (5-9Hz: 3.5mm amplitude; 9-150Hz: 9.8m/s² acceleration)
Power Specifications
Input Voltage	24 VDC (rated 19.2-28.8 VDC)
Power Consumption	≤12W (typical)
Inrush Current	≤30A (5ms)
Isolation	1,000 VAC (20mA for 1 minute between power and FG terminals)

Packing & Delivery

100% brand New and Original Factory Seal!
Warranty: 1 year
Package: Original packing with cartons
Delivery time: Shipped in 3-7 days after payment
All the goods will be tested before shipment
