Name: PFXGP4301TADC Proface Rugged, Panel-mounted HMI
Brand: Xiamen Online Union Technology Co., Ltd
SKU: PFXGP4301TADC
Price: 50.00 USD
Availability: InStock

Home > Products > Proface Module >

PFXGP4301TADC Proface Rugged, Panel-mounted HMI

Proface rugged HMI panel

Proface panel-mounted HMI module

Proface HMI with warranty

Place of Origin:

Japan

Brand Name:

Proface

Model Number:

PFXGP4301TADC

Request A Quote

Product Details

Family:

HMI

Series:

GP4000 Series

Size:

Model:

GP4301T

Highlight:

Proface rugged HMI panel

Proface panel-mounted HMI module

Proface HMI with warranty

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

PFXGP4301TADC Proface Rugged, Panel-mounted HMI

Get Best Price

Video

PFXGP4301TAD Proface 5.7 Touch Panel Display

Get Best Price

PFXGP4401TAD Proface HMI Touch Panel

Get Best Price

PFXGP4601TADC Proface Operator Interface 12.1 TFT Touchscreen Touch Panel Proface

Get Best Price

Contact Now

Product Description

PFXGP4301TADC Proface Rugged, Panel-mounted HMI

The PFXGP4301TADC is a rugged, panel-mounted HMI featuring a TFT color LCD display and resistive analog touch panel. Designed as an operator interface for monitoring and controlling industrial processes, this device offers exceptional reliability and durability in harsh environments. With conformal coating on its PCB for enhanced resistance to dust, moisture, and chemical exposure, it's ideal for factory automation, process control, and machinery operation applications.

Technical Specifications

Display

Type	TFT color LCD
Size	5.7 inches
Resolution	320 x 240 pixels (QVGA)
Effective Display Area	115.2 mm (width) x 86.4 mm (height) [4.54 x 3.40 inches]
Colors	65,536 colors (non-blinking) / 16,384 colors (blinking)
Backlight	White LED (non-user-replaceable; rated for 50,000+ hours of continuous operation at 25°C before brightness decreases to 50%)
Brightness Control	16 levels (adjustable via touch panel or software)

Touch Panel

Type	Resistive film (analog)
Resolution	1,024 x 1,024
Lifetime	1,000,000+ touches

Languages and Fonts

Japanese	6,962 characters (JIS Standards 1 & 2, including 607 non-kanji characters)
ANK (Alphanumeric)	158 characters
Additional Languages	Korean, Traditional Chinese, Simplified Chinese, and Cyrillic (can be added via screen editor font settings)
Font Sizes	Standard fonts (8x8, 8x16, 16x16, 32x32 pixels), stroke fonts (6 to 127 pixels), and image fonts (8 to 72 pixels). Standard fonts can be expanded up to 8x in width and height.

Electrical Specifications

Rated Input Voltage	24 VDC
Input Voltage Range	19.2 to 28.8 VDC
Allowable Voltage Drop	7 ms or less
Power Consumption	6.8 W or less
Inrush Current	30 A or less
Noise Immunity	2 kV (power port), 1 kV (signal ports) via IEC61000-4-4
Voltage Endurance	1,000 VAC, 20 mA for 1 minute (between power terminal and FG terminals)
Insulation Resistance	500 VDC, 10 MΩ or more (between power terminal and FG terminals)

Environmental Specifications

Operating Temperature	0°C to 50°C (some sources indicate 0°C to 55°C)
Storage Temperature	-20°C to 60°C
Operating Humidity	85% RH (non-condensing, wet bulb temperature: 39°C or less)
Storage Humidity	85% RH (non-condensing, wet bulb temperature: 39°C or less)
Ingress Protection	IP65F (dust-tight and protected against water jets; equivalent to NEMA 4X, 12, and 13 ratings)
Altitude	Up to 2,000 meters (800 to 1,114 hPa)

Mechanical Specifications

Weight	Approximately 0.62 kg (main unit only)
Dimensions	315 mm (width) x 241 mm (height) x 56 mm (depth)
Panel Cutout Dimensions	301.5 mm (width) x 227.5 mm (height) (panel thickness: 1.6 to 5 mm)

Interfaces

Serial Ports: 2x RS-232C/RS-422/RS-485 (configurable)
Ethernet: 1x 10BASE-T/100BASE-TX (RJ-45 connector)
USB: 1x USB Type-A (for peripheral devices) and 1x USB Mini-B (for programming and data transfer)
SD Card Slot: For storage expansion and data logging

Memory

Application Memory	16 MB FLASH EPROM (for storing programs and data)
Backup Memory	320 KB SRAM with battery backup (for retaining data during power failures)

Packing & Delivery

100% brand new and original factory sealed
Warranty: 1 year
Package: Original packing with cartons
Delivery time: Shipped in 3-7 days after payment
All goods thoroughly tested before shipment
