Name: E2KQ-X10ME1 2M OMRON Chemical-resistant Proximity Sensor
Brand: Xiamen Online Union Technology Co., Ltd
SKU: E2KQ-X10ME1 2M
Price: 50.00 USD
Availability: InStock

Home > Products > OMRON Parts >

E2KQ-X10ME1 2M OMRON Chemical-resistant Proximity Sensor

OMRON chemical-resistant proximity sensor

2M OMRON proximity sensor

E2KQ-X10ME1 industrial sensor

Place of Origin:

Japan

Brand Name:

OMRON

Model Number:

E2KQ-X10ME1 2M

Request A Quote

Product Details

Sensing Head Size:

M18

Sensing Distance:

10 Mm

Setting Distance:

6 To 10 Mm

Response Frequency:

35 Hz

Power Supply Voltage:

12 To 24 VDCripple (p-p) 10% Max.

Operating Voltage Range:

10 To 30 VDC

Current Consumption:

15 MA Max.

Control Output (Output Type):

NPN

Control Output (Switching Capacity):

100 MA Max.

Degree Of Protection:

IEC: IP66 Company Standard: Oil-proof

Highlight:

OMRON chemical-resistant proximity sensor

2M OMRON proximity sensor

E2KQ-X10ME1 industrial sensor

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

R88M-K3K020F-S2 OMRON G5 Series AC Servo Motor

Get Best Price

PL-05N OMRON Inductive Proximity Sensor

Get Best Price

E39-S65D OMRON Photoelectric Sensor

Get Best Price

E2KQ-X10ME1 2M OMRON Chemical-resistant Proximity Sensor

Get Best Price

Contact Now

Product Description

E2KQ-X10ME1 2M OMRON Chemical-resistant Proximity Sensor

Product Description

Omron E2KQ-X10ME1 2M Chemical-resistant Proximity Sensor

Chemical-resistant Proximity Sensor, M18, Unshielded, Sensing distance: 10 mm, DC 3-wire, NPN output, NO, Pre-wired model, 2 m.

The E2KQ-X10ME1 2M is a chemical-resistant capacitive proximity switch manufactured by Omron, designed for precise detection of conductive and dielectric objects in harsh industrial environments. It features a fluororesin-coated case that provides excellent resistance to chemicals and oil, making it suitable for applications in food processing, pharmaceutical manufacturing, and chemical handling. The switch has a standard detection distance of 10 mm, with an adjustable range of 6 to 10 mm, allowing for flexibility in various setups. It comes with a 2-meter pre-wired cable for easy installation and connection.

Technical Specifications

Type	Capacitive Proximity Switch
Brand	Omron
Model	E2KQ-X10ME1 2M
Detection Distance	Standard 10 mm, adjustable range 6 to 10 mm
Detectable Objects	Conductors and dielectrics (standard sensing object: grounded metal plate 50 × 50 × 1 mm)
Response Frequency	35 Hz
Power Supply Voltage	12 to 24 VDC (operating range: 10 to 30 VDC), ripple (p-p): 10% max.
Current Consumption	15 mA max.
Control Output	Switch Capacity: 100 mA Residual Voltage: 1.5 V max. (load current: 100 mA, cable length: 2 m)
Output Type	DC 3-wire, NPN, NO (Normally Open)
Indicators	Detection indicator (red LED) for clear status indication
Protection Circuits	Reverse polarity protection, surge suppressor
Ambient Temperature Range	Operating: -10 to 55°C Storage: -25 to 55°C (no icing or condensation)
Ambient Humidity Range	Operating/storage: 35% to 85% (no condensation)
Temperature Influence	±15% max. of sensing distance at 23°C in the temperature range of -10 to 55°C
Voltage Influence	±2% max. of sensing distance at rated voltage ±20%
Insulation Resistance	50 MΩ min. (at 500 VDC) between current-carrying parts and case
Dielectric Strength	500 VAC, 50/60 Hz for 1 min between current-carrying parts and case
Vibration Resistance	10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions
Shock Resistance	500 m/s², 3 times each in X, Y, and Z directions
Degree of Protection	IP66 (IEC), in-house standards: oil-resistant
Connection Method	Pre-wired (standard cable length: 2 m)
Weight (Packed State)	Approximately 150 g
