Name: 1756-EN2T Allen Bradley CLX ENet/IP 100M Communication Module
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 1756-EN2T
Price: 50.00 USD
Availability: InStock

Home > Products > Allen Bradley PLC >

1756-EN2T Allen Bradley CLX ENet/IP 100M Communication Module

Allen Bradley CLX Ethernet/IP module

1756-EN2T communication module

Allen Bradley PLC 100M module

Place of Origin:

USA

Brand Name:

Allen Bradley

Model Number:

1756-EN2T

Request A Quote

Product Details

Insulation Voltage:

30 Volts Continuous

Current Draw:

1 Amp

Current Rating:

1.2 Amps

Power Dissipation:

6.2 W

Ethernet-IP Communication Rate:

10/100 Mbps

Highlight:

Allen Bradley CLX Ethernet/IP module

1756-EN2T communication module

Allen Bradley PLC 100M module

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

2085-OF4 Allen Bradley Micro800 4 Point Analog Output Module

Get Best Price

2085-IF8 Allen Bradley Input Module

Get Best Price

2080-L50E-48QWB Allen Bradley Micro850 48 I/O ENet/IP Controller

Get Best Price

1794-IE8 Allen Bradley Flex 8 Point Analog Input Module

Get Best Price

Contact Now

Product Description

1756-EN2T Allen Bradley CLX ENet/IP 100M Communication Module

The 1756-EN2T is an EtherNet/IP communication module for the Allen-Bradley ControlLogix programmable automation controller (PAC) system. It functions as a network bridge, connecting the ControlLogix backplane to an Ethernet network for high-speed data exchange, device control, and integration within a CIP (Common Industrial Protocol) network architecture.

Technical Specifications

Communication & Network

Primary Protocol: EtherNet/IP (CIP) for industrial control and information exchange

Transmission Rate: 10/100 Mbps (auto-negotiating)

Physical Ports: Two independent RJ45 ports supporting network redundancy and device-level ring (DLR) topologies

Connection Capacity: Supports up to 256 CIP connections and 128 TCP connections

Additional Interface: One USB 1.1 port for local configuration and firmware updates

Electrical & Physical

Power Consumption: 5.1 Watts from the 5.1V DC backplane

Current Draw: 1.0 Ampere at 5.1V DC

Heat Dissipation: 17.4 BTU/hour

Isolation: 30V continuous isolation (tested at 980V AC) between Ethernet/USB ports and controller backplane

Slot Width: Occupies 1 slot in any ControlLogix chassis

Environmental Ratings

Operating Temperature: 0°C to 60°C (32°F to 140°F)

Storage Temperature: -40°C to 85°C (-40°F to 185°F)

Relative Humidity: 5% to 95% (non-condensing)

Certifications: CE, ATEX, c-UL-us, and other global industrial standards

Packing & Delivery

100% brand new and original factory sealed
1-year warranty included
Original packaging with cartons
Shipped within 3-7 days after payment
All goods thoroughly tested before shipment
