Name: 6ES7414-2XL07-0AB0 Siemens SIMATIC S7-400 CPU 414-2 Central Processing Unit
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 6ES7414-2XL07-0AB0
Price: 50.00 USD
Availability: InStock

Home > Products > SIEMENS PLC Module >

6ES7414-2XL07-0AB0 Siemens SIMATIC S7-400 CPU 414-2 Central Processing Unit

Siemens S7-400 CPU 414-2 PLC

SIMATIC S7-400 central processing unit

Siemens PLC module with warranty

Place of Origin:

GERMANY

Brand Name:

SIEMENS

Model Number:

6ES7414-2XL07-0AB0

Request A Quote

Product Details

Product Series:

SIMATIC S7-400

CPU Type:

CPU 414-2 (Standard CPU)

Work Memory:

2 MB (RAM) - 1 MB Code, 1 MB Data

Load Memory:

Expandable Via MMC Card (up To 8 GB)

Interfaces:

1x MPI/DP (12 Mbit/s), 1x PROFIBUS DP (Master/Slave)

Bit Operation Time:

0.06 µs (Binary) / 0.09 µs (Word)

I/O Capacity:

Max 2048 Digital I/O / 256 Analog I/O (across All Racks)

Expansion Racks:

Up To 32 (with Interface Modules)

Highlight:

Siemens S7-400 CPU 414-2 PLC

SIMATIC S7-400 central processing unit

Siemens PLC module with warranty

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

6ES7414-2XL07-0AB0 Siemens SIMATIC S7-400 CPU 414-2 Central Processing Unit

Get Best Price

6ES7318-3EL01-0AB0 Siemens SIMATIC S7-300 CPU 319-3 PN/DP

Get Best Price

6ES7231-4HF32-0XB0 Siemens SIMATIC S7-1200 Analog Input Module

Get Best Price

6AU1445-2AD00-0AA0 Siemens SIMOTION D445-2 DP/PN Motion Controller

Get Best Price

Contact Now

Product Description

Product Overview

The Siemens 6ES7414-2XL07-0AB0 is a high-performance Central Processing Unit (CPU) from the SIMATIC S7-400 series, specifically the CPU 414-2 model. As a cornerstone of the S7-400 automation platform, this controller is engineered for demanding medium-to-large scale automation tasks that require high processing speeds, extensive memory, and robust multi-protocol communication capabilities.

It serves as the central processing unit for complex industrial systems, designed to handle intricate logic control, advanced process regulation, and synchronized motion control. With its powerful processor and expanded memory, the CPU 414-2 delivers exceptional performance for sophisticated machinery and distributed automation systems, offering a reliable and scalable solution for critical industrial applications.

Series: SIMATIC S7-400 (Modular PLC System)
Model: CPU 414-2 (Standard Performance)
Work Memory: 2 MB (1 MB for code, 1 MB for data)
Communication: Integrated MPI/DP (12 Mbit/s) and PROFIBUS DP (Master/Slave)
Key Feature: High-speed instruction processing, large memory capacity, and flexible expansion capabilities

Key Features & Benefits

High-Performance Processing Power

Rapid Execution: Delivers extremely short bit operation times (0.06 µs for binary operations), ensuring instantaneous response to critical process events and high-speed I/O updates
Large Memory Capacity: Standard 2 MB work memory for extensive user programs and complex data structures, expandable using Micro Memory Card (MMC) up to 8 GB
Complex Calculations: Capable of handling complex floating-point arithmetic, advanced function blocks, and large-scale data processing

Integrated Multi-Protocol Communication

Dual-Interface Architecture: Features MPI/DP (12 Mbit/s) for programming and HMI connection, plus PROFIBUS DP (Master/Slave) for high-speed distributed I/O communication
Global Data Exchange: Supports S7 communication protocols for seamless data exchange with other S7 PLCs, HMI panels, and SCADA systems

Advanced Diagnostics & System Functions

Comprehensive Diagnostics: Detailed diagnostic information for CPU, I/O modules, and communication networks with buffer memory for fault history analysis
Real-Time Clock: Integrated hardware clock with battery backup for precise time-stamping and scheduling
Flexible Operating Modes: Supports RUN, STOP, and RUN-P modes for online program modifications without stopping operations

Scalability & Modularity

Extensive Expansion: Controls up to 32 expansion racks or numerous distributed I/O stations, supporting up to 2048 I/O points
Technology Functions: Integrated technology functions for motion control and process control, reducing need for external hardware

Technical Specifications

Model Number	6ES7414-2XL07-0AB0
Product Series	SIMATIC S7-400
CPU Type	CPU 414-2 (Standard CPU)
Work Memory	2 MB (RAM) - 1 MB Code, 1 MB Data
Load Memory	Expandable via MMC Card (up to 8 GB)
Interfaces	1x MPI/DP (12 Mbit/s), 1x PROFIBUS DP (Master/Slave)
Bit Operation Time	0.06 µs (Binary) / 0.09 µs (Word)
I/O Capacity	Max 2048 digital I/O / 256 analog I/O (across all racks)
Expansion Racks	Up to 32 (with Interface Modules)
Power Supply	24 V DC (via backplane bus from Power Supply Module)
Power Consumption	Approx. 1.8 A at 5V DC (typical)
Dimensions (H x W x D)	125 mm x 40 mm x 120 mm
Weight	Approx. 0.3 kg
Operating Temperature	0°C to 60°C (32°F to 140°F)
Protection Rating	IP20 / NEMA 1 (Type 1)
Certifications	UL, cUL, CE, C-Tick, CCC, ATEX, IECEx (for specific zones)
Required Accessory	Micro Memory Card (MMC) - Order separately (e.g., 6ES7953-8LF31-0AA0)

Typical Applications

Complex Machinery Control: CNC machines, multi-axis robotic cells, rotary printing presses, and packaging lines requiring synchronized motion
Process Automation: Chemical processing, water/wastewater treatment plants, and batch control systems requiring extensive analog handling and multi-loop PID control
Distributed Control Systems (DCS): Master controller for large-scale distributed I/O networks in assembly lines, material handling systems, and power plants
Building Automation: Central control for HVAC systems, lighting, and security in large commercial buildings and skyscrapers
Automotive Manufacturing: Control of body shops, paint lines, and final assembly conveyors with high-speed I/O requirements
