Name: 779680-01 National Instruments 4-channel, 24-bit Dynamic Signal Acquisition Module
Brand: Xiamen Online Union Technology Co., Ltd
SKU: 779680-01
Price: 50.00 USD
Availability: InStock

Home > Products > National Instruments Module >

779680-01 National Instruments 4-channel, 24-bit Dynamic Signal Acquisition Module

National Instruments 4-channel acquisition module

24-bit dynamic signal module

NI 779680-01 signal acquisition module

Place of Origin:

Japan

Brand Name:

National Instruments

Model Number:

779680-01

Request A Quote

Product Details

Highlight:

National Instruments 4-channel acquisition module

24-bit dynamic signal module

NI 779680-01 signal acquisition module

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

779680-01 National Instruments 4-channel, 24-bit Dynamic Signal Acquisition Module

Get Best Price

781639-01 National Instruments Single-port, High-speed CAN Flexible Interface Module

Get Best Price

778836-01 National Instruments 8-channel, Bidirectional Digital I/O Module

Get Best Price

778465-01 National Instruments 4-channel, High-power Digital Output Module

Get Best Price

Contact Now

Product Description

National Instruments 779680-01 4-channel, 24-bit Dynamic Signal Acquisition Module

The National Instruments 779680-01, also known as the NI 9234 C Series Sound and Vibration Input Module, is a specialized data acquisition device designed for measuring acoustic and vibrational signals in industrial and laboratory environments.

The NI 9234 is a 4-channel, 24-bit dynamic signal acquisition module optimized for sound and vibration measurements. It is compatible with CompactDAQ or CompactRIO systems, enabling integration into modular test and measurement setups. This module supports both IEPE (Integrated Electronic Piezoelectric) and non-IEPE sensors, such as accelerometers, microphones, tachometers, and proximity probes, making it suitable for applications like machinery diagnostics, structural analysis, and audio testing.

Technical Specifications

Channels	4 differential analog inputs
Resolution	24 bits
Sampling Rate	Up to 51.2 kS/s/channel (kilosamples per second per channel)
Input Range	±5 V (fixed range)
Coupling	Software-selectable AC/DC
Input Impedance	1 MΩ (AC coupling), 500 Ω (DC coupling)
Filters	Anti-aliasing filters with automatic adjustment based on sampling rate
Connector Type	BNC inputs for sensor connectivity
Isolation	Channel-to-channel and channel-to-ground isolation (250 Vrms) for noise immunity
Overvoltage Protection	±100 V continuous input protection
Power Requirements	12 W (typical) via CompactDAQ/CompactRIO chassis
Software Compatibility	NI-DAQmx Driver: Supports configuration and data logging in NI LabVIEW, LabWindows/CVI, and Measurement Studio Third-Party Integration: API support for Python, ANSI C, C#.NET, and MathWorks MATLAB
Environmental	Operating temperature: -20°C to 70°C Storage temperature: -40°C to 85°C Humidity: 5% to 95% (non-condensing) Certifications: RoHS compliant, CE marked

Our Services

All our products are new and original, and of good quality
Our prices are very competitive
We have a large quantity in stock, so we could help the customers to get the components which are difficult to get
All inquiries will be valued and will reply in 24 hours

Packing & Delivery

100% brand New and Original Factory Seal!
Warranty: 1 year
Package: Original packing with cartons
Delivery time: Shipped in 3-7 days after payment
All the goods will be tested before shipment
