Product Description

PFXST6500TADE Proface 10.4" Touch Panel Display 24VDC, GP-ProEX Model

The Proface PFXST6500TADE is a 10.4-inch Basic Human-Machine Interface (HMI) panel designed for industrial automation applications. It belongs to the ST6000 Series and offers a high-resolution display with advanced touch functionality. This HMI is widely used in factory automation, process control, and machine operation systems, providing intuitive visualization and control capabilities.

Technical Specifications

Display Specifications

Display Type	TFT Color LCD
Display Size	10.4 inches
Resolution	800 x 600 pixels (SVGA)
Effective Display Area	211.2 mm (W) x 158.4 mm (H)
Display Colors	16 million colors
Backlight	White LED (non-replaceable by user; service required for replacement)
Backlight Lifetime	50,000 hours minimum (at 25°C continuous operation, brightness reduced to 25% of original)
Brightness Adjustment	16-level adjustment via touch panel or software

Touch Panel Specifications

Touch Panel Type	Resistive film (analog, single-touch)
Touch Panel Resolution	1,024 x 1,024
Touch Panel Lifetime	1,000,000 touches minimum

Electrical Specifications

Input Voltage	24 VDC
Rated Voltage Range	19.2 VDC to 28.8 VDC
Voltage Drop	≤ 10 ms
Power Consumption	Maximum: 10.56 W Without external device power supply: ≤ 7.51 W Standby mode (backlight off): ≤ 4.56 W
Inrush Current	≤ 30 A
Insulation Strength	1,000 VAC, 20 mA for 1 minute (between power terminals and FG terminal)
Insulation Resistance	≥ 10 MΩ at 500 VDC

Environmental Specifications

Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to +60°C
Operating Humidity	10% RH to 90% RH (non-condensing, wet-bulb temperature ≤ 39°C)
Storage Humidity	≤ 85% RH (non-condensing, wet-bulb temperature ≤ 39°C)
Dust Resistance	≤ 0.1 mg/m³ (insulation class)
Pollution Degree	Pollution Degree 2
Air Quality	No corrosive gases
Atmospheric Pressure (Operating Altitude)	800 hPa to 1,114 hPa (altitude ≤ 2,000 meters)

Packing & Delivery

100% brand New and Original Factory Seal!
Warranty: 1 year
Package: Original packing with cartons
Delivery time: Shipped in 3-7 days after payment
All the goods will be tested before shipment
