Name: PFXGP4301TAD Pro-face GP4000 Series HMI Touch Screen
Brand: Xiamen Online Union Technology Co., Ltd
SKU: PFXGP4301TAD
Price: 50.00 USD
Availability: InStock

Home > Products > Proface Module >

PFXGP4301TAD Pro-face GP4000 Series HMI Touch Screen

Proface GP4000 HMI touch screen

GP4000 Series industrial touch panel

Proface HMI module with warranty

Place of Origin:

Japan

Brand Name:

Pro-face

Model Number:

PFXGP4301TAD

Request A Quote

Product Details

Product Series:

GP4000 Series

Display Type:

5.7" TFT Active Matrix LCD

Display Colors:

65,536 Colors

Resolution:

320 X 240 Pixels (QVGA)

Touch Panel:

Resistive (Analog)

Backlight:

White LED (User-replaceable, 50,000+ Hrs Life)

CPU:

GED669 (High-speed Processor)

Memory:

8 MB - 16 MB (Application/Backup) Varies By Revision

Communication Ports:

Ethernet (RJ-45), RS-232C (D-Sub 9), RS-422/485

USB Ports:

1x USB Type-A (Host), 1x USB Mini-B (Device)

Expansion Slot:

1x SD/SDHC Card Slot

Input Voltage:

24 V DC (Range: 20.4 ~ 28.8 V DC)

Highlight:

Proface GP4000 HMI touch screen

GP4000 Series industrial touch panel

Proface HMI module with warranty

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

PFXGP4401TAD Proface 7.5-inch Modular Touchscreen HMI

Get Best Price

Video

PFXGP4301TADC Proface Rugged, Panel-mounted HMI

Get Best Price

Video

PFXGP4301TAD Proface 5.7 Touch Panel Display

Get Best Price

PFXGP4401TAD Proface HMI Touch Panel

Get Best Price

Contact Now

Product Description

Pro-face GP4000 Series HMI Touch Screen

The Pro-face PFXGP4301TAD is a rugged and versatile Human-Machine Interface (HMI) belonging to the industry-leading GP4000 Series. Designed as a "Modular Type" operator terminal, it bridges the gap between basic text displays and advanced graphical interfaces. It is engineered to provide high-performance visualization and control for industrial machinery, offering a 5.7-inch TFT color display, extensive connectivity options, and robust environmental protection.

As part of the GP4000 family, this model is optimized for applications requiring reliable operation in harsh environments. It features a high-speed CPU for smooth graphics rendering, multiple communication ports for seamless integration with PLCs and SCADA systems, and front-panel IP65F protection, making it ideal for factory floors, packaging lines, and process control systems.

Key Product Highlights

Series: GP4000 Series (Modular Type)
Type: Touchscreen HMI / Operator Terminal
Display: 5.7" TFT LCD (65,536 colors)
Resolution: 320 x 240 pixels (QVGA)
Connectivity: Ethernet, RS-232C/422/485, USB 2.0
Protection Rating: IP65F (Front Panel) / NEMA 4X
Key Feature: High-speed processing, SD card expansion, and web-server capabilities

Key Features & Benefits

High-Visibility Color Display

TFT LCD Technology: Features a 5.7-inch active-matrix TFT display capable of showing 65,536 colors, providing clear visualization of process variables, alarms, and trends
High Resolution: With a QVGA (320 x 240) resolution, it offers crisp text and detailed graphics, significantly improving operability over older monochrome displays
Adjustable Backlight: White LED backlight with 16-level brightness adjustment via software or touch keys, extending lamp life to over 50,000 hours (at 25°C)

Powerful Performance & Connectivity

High-Speed CPU: Equipped with a GED669 processor, offering significantly faster screen switching and data processing compared to previous generations, capable of handling animations and complex recipe management smoothly
Multi-Protocol Communication: Comes standard with Ethernet (10BASE-T/100BASE-TX) for data acquisition and remote monitoring. It also supports RS-232C and RS-422/485 for direct PLC connection
Peripheral Support: Includes USB 2.0 (Type-A and Mini-B) ports for connecting printers, barcode scanners, or mice, and an SD card slot for program backup, firmware updates, and data logging

Rugged & Reliable Design

IP65F Front Panel: The front panel is rated IP65F (dust-tight and protected against water jets), making it suitable for washdown environments and oily factory floors. It is also certified for NEMA 4X, 12, and 13
Wide Operating Temperature: Operates reliably in temperatures ranging from 0°C to 50°C (32°F to 122°F), with storage capability from -20°C to 60°C
Shock & Vibration Resistance: Designed to withstand the mechanical stresses of industrial environments, complying with IEC/EN61131-2 standards for vibration and shock

Advanced Functionality

Web Server Capability: The Ethernet port allows the HMI to act as a web server, enabling operators to monitor and control the machine via a standard web browser on a PC or tablet without special software
Remote HMI Support: Compatible with Pro-face Remote HMI software, allowing control via tablets or smartphones over Wi-Fi or Ethernet
Data Logging: With the SD card slot and large internal memory, it can log historical data for predictive maintenance and quality control
