Name: ATS22D47Q Schneider Electric Altistart 22 Soft Starter
Brand: Xiamen Online Union Technology Co., Ltd
SKU: ATS22D47Q
Price: 50.00 USD
Availability: InStock

Home > Products > Schneider Module >

ATS22D47Q Schneider Electric Altistart 22 Soft Starter

Schneider Electric Altistart 22 soft starter

ATS22D47Q motor control module

Schneider soft starter with warranty

Place of Origin:

French

Brand Name:

Schneide

Model Number:

ATS22D47Q

Request A Quote

Product Details

Product Series:

Altistart 22

Product Type:

Soft Starter (AC-53A)

Power Supply:

3-Phase 230 V – 440 V AC (±15% Tolerance)

Frequency:

50/60 Hz (±10%)

Starting Current:

Adjustable: 0.4 To 1 X Icl (Current Limit)

Control Voltage:

230 V AC (via Power Circuit)

Discrete Inputs:

3 (LI1, LI2, LI3) - Logic 24V DC

Discrete Outputs:

2 Relay Outputs (NO/NC) - 230V AC, 5A

Highlight:

Schneider Electric Altistart 22 soft starter

ATS22D47Q motor control module

Schneider soft starter with warranty

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

XVBC2B3 Schneider Electric Harmony XVB Series Green Indicator Light

Get Best Price

BCH2MM2023CA6C Schneider Electric Lexium 28 Servo Motor

Get Best Price

TM2AMI2HT Schneider Analog Input Module, Modicon M238 Logic Controller, 2 Inputs Voltage

Get Best Price

ATV312H037N4 Schneider Variable Speed Drive, ATV312

Get Best Price

Contact Now

Product Description

Schneider Electric Altistart 22 Soft Starter - ATS22D47Q

The Schneider Electric ATS22D47Q is a robust and compact Soft Starter from the industry-leading Altistart 22 series. Designed specifically for asynchronous (induction) motors, this device provides smooth, controlled acceleration and deceleration, significantly reducing mechanical stress on motors and connected equipment. Engineered to replace traditional star-delta starters, it offers a space-saving, cost-effective solution with advanced features for diverse industrial applications.

Technical Specifications

Parameter	Value
Series	Altistart 22
Type	Electronic Soft Starter (AC-53A)
Motor Type	Asynchronous (Induction) Motor
Power Rating	22 kW (400V) / 11 kW (230V)
Current Rating	47 A (Main Circuit)
Voltage Range	230V - 440V AC (3-Phase)
Dimensions	265 x 130 x 169 mm

Key Features

Integrated bypass, heat sink, and Modbus RS485 communication
Internal thyristor bypass for reduced power dissipation (48W)
Built-in Modbus with RJ45 port (4800, 9600, or 19200 bps)
Current limiting (3.5x nominal current)
Comprehensive motor protection systems
3 Digital Inputs and 2 Relay Outputs
LED status indicators and easy programming

Motor Control & Protection Features

Smooth Operation

Soft Start/Stop eliminates mechanical shocks
Prevents water hammer effects in piping systems
Controlled voltage ramp-up and ramp-down
Reduces voltage dips in power supply network

Advanced Protection

Phase failure protection
Motor thermal protection via PTC probe input
Starter thermal protection
Protection against short circuits and overloads

Connectivity & Integration

Built-in Modbus RTU protocol over RS485 interface
Seamless integration with SCADA systems, PLCs, and HMIs
Remote monitoring and parameter setting capabilities
Configurable via built-in keypad or PowerSuite PC software

Design Advantages

Compact design saves control panel space
Pre-assembled heat sink for immediate installation
Internal bypass extends component life
"Plug-and-play" solution for modern automation systems
