Name: BCH2MM2023CA6C Schneider Electric Lexium 28 Servo Motor
Brand: Xiamen Online Union Technology Co., Ltd
SKU: BCH2MM2023CA6C
Price: 50.00 USD
Availability: InStock

Home > Products > Schneider Module >

BCH2MM2023CA6C Schneider Electric Lexium 28 Servo Motor

Schneider Electric Lexium 28 servo motor

Lexium 28 servo motor with warranty

Schneider Module servo motor

Place of Origin:

French

Brand Name:

Schneide

Model Number:

BCH2MM2023CA6C

Request A Quote

Product Details

Product Series:

Lexium 28 / BCH2

Motor Type:

Brushless AC Servo Motor

Rated Power:

2000 W (2 KW)

Rated Voltage:

220 V AC (3-Phase)

Rated Current:

9.95 A (Continuous) / 32.85 A (Peak)

Rated Speed:

2000 RPM

Max Speed:

3000 RPM

Rated Torque:

9.55 N·m

Highlight:

Schneider Electric Lexium 28 servo motor

Lexium 28 servo motor with warranty

Schneider Module servo motor

Payment & Shipping Terms

Minimum Order Quantity

Price

1-99$

Packaging Details

Brand New Original

Delivery Time

in stock / 1-3 work days

Payment Terms

T/T

Supply Ability

999

XVBC2B3 Schneider Electric Harmony XVB Series Green Indicator Light

Get Best Price

BCH2MM2023CA6C Schneider Electric Lexium 28 Servo Motor

Get Best Price

TM2AMI2HT Schneider Analog Input Module, Modicon M238 Logic Controller, 2 Inputs Voltage

Get Best Price

ATV312H037N4 Schneider Variable Speed Drive, ATV312

Get Best Price

Contact Now

Product Description

Schneider Electric Lexium 28 Servo Motor - BCH2MM2023CA6C

The Schneider Electric BCH2MM2023CA6C is a high-performance Brushless AC Servo Motor from the Lexium 28 series, specifically the BCH2 motor line. Designed for compact and high-dynamic motion control applications, this motor delivers exceptional speed, torque, and precision in a standardized 130mm flange form factor. Engineered to work seamlessly with Schneider's Lexium 28 servo drives, it forms an optimized servo bundle that is cost-effective, energy-efficient, and embedded with safety features.

Product Specifications

Specification	Details
Series	Lexium 28 / BCH2 Series
Type	Brushless AC Servo Motor
Power Rating	2000 W (2 kW)
Flange Size	130 mm (Asian Standard)
Shaft	22 mm diameter (Keyed) with Oil Seal
Encoder	20-bit Single-Turn Absolute
Protection	IP50 / IP65 (depending on mounting)
Compatibility	Lexium 28 Servo Drives (e.g., LXM28AU20M3X)

Key Features & Benefits

High Dynamic Performance

Optimized Inertia: Designed with a rotor inertia of 13.5 kg.cm², providing excellent balance between acceleration capability and load matching for general automation tasks
High Speed: Capable of reaching a maximum mechanical speed of 3000 RPM, enabling rapid cycle times in packaging, assembly, and material handling applications
Precision Control: Equipped with a 20-bit absolute encoder ensuring precise position feedback even after power loss, eliminating the need for homing routines

Robust Construction & Environmental Protection

IP65/IP50 Rating: Offers IP65 protection (dust-tight and protected against water jets) when mounted correctly (IM B5 or IM V1), making it suitable for washdown environments, food processing, and outdoor applications
Oil Seal: Integrated oil seal on the shaft prevents lubricant leakage and ingress of contaminants, extending motor life in dirty or oily environments
Natural Convection Cooling: 130mm frame utilizes natural air convection, eliminating the need for cooling fans, reducing noise, and minimizing maintenance requirements

Seamless Integration & Connectivity

MIL Connector: Standard MIL (D-Sub) connector for power and feedback provides robust, industry-standard connection that resists vibration
Plug-and-Play with Lexium 28: Pre-configured parameters allow for instant recognition and auto-tuning when connected to Lexium 28 series drives, significantly reducing commissioning time
Safety Integrated: Supports safe torque off (STO) and other safety functions via the connected drive, meeting SIL 3 / PL e safety standards

Compact & Efficient Design

Space-Saving: 130mm flange is significantly more compact than traditional 180mm motors for the same power class, saving valuable cabinet space
Energy Efficiency: High-efficiency motor design reduces heat generation and power consumption, contributing to lower operational costs
