TSXDSZ32R5 Schneider Electric 32-Output Relay Module

Product Details:

Place of Origin:	China
Brand Name:	Schneider
Model Number:	TSXDSZ32R5

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$99
Packaging Details:	New sealed
Delivery Time:	In stock/1-3days
Payment Terms:	T/T
Supply Ability:	5000

Contact Now

Detailed Product Description

Highlight:

industrial automation schneider module

automation control schneider module

plc controller schneider module

TSXDSZ32R5 Schneider Electric 32-Output Relay Module

The TSXDSZ32R5 is a 32-output relay discrete module from Schneider Electric's Modicon TSX Micro automation platform. This module is designed for industrial automation and control systems, offering 32 screw terminal block outputs with normally open (NO) contacts. It supports a wide range of output voltage limits, from 19 to 264 V AC and 10 to 34 V DC. The module has a thermal current rating of 2 A and a power consumption of up to 200 VA depending on the voltage and load type. It features a response time of less than 10 ms, ensuring rapid and reliable operation. The TSXDSZ32R5 also includes safety features such as an isolation voltage of 1500 V for 1 second and an insulation resistance of at least 10 megaohms. This module is RoHS compliant, ensuring environmental sustainability

Technical specifcations for TSXDSZ32R5

Parameter  :  Specification
Product Range  :  Modicon TSX Micro automation platform
Product Type  :  Relay discrete output module
Discrete Output Number   : 32 screw terminal block
Contact Type  :  Normally Open (NO)
Output Voltage Limits  :  19...264 V AC, 10...34 V DC
Thermal Current  :  2 A
Power Consumption in VA
- 24 V AC-12 resistive  :  50 VA
- 24 V AC-15 inductive  :  24 VA
- 48 V AC-12 resistive :   100 VA
- 110...120 V AC-12 resistive  :  200 VA
- 200...240 V AC-12 resistive  :  200 VA
- 48 V AC-15 inductive  :  50 VA
- 110...120 V AC-15 inductive  :  50 VA
- 200...240 V AC-15 inductive  :  50 VA
Power Consumption in W
- 24 V DC-12 resistive  :  24 W
- 24 V DC-13 inductive  :  24 W
Response Time    < 10 ms
Current Consumption   : 175 mA
Power Dissipation  :  3.5 W
Isolation Voltage   : 1500 V for 1 second
Insulation Resistance    >= 10 megaohms
Compliance  :  RoHS compliant since 0919
Warranty Period  :  18 months
