MC-4/11/22-400 Schneider Relay Module
MC-4/11/22-400 is a high-performance servo drive under the ELAU brand, which is an important component of the PacDrive MC-4 servo system. It is designed specifically for industrial automation applications, with compact design, high power density, and excellent reliability. It uses advanced control algorithms to achieve precise motor position, speed, and torque control, supports multiple communication interfaces such as CANopen and EtherCAT, and is easy to integrate with other industrial equipment. Its design is reasonable, easy to install, and equipped with complete protection and fault diagnosis functions. It is suitable for various industrial automation fields such as packaging machinery, food and beverage processing, material handling equipment, printing and labeling machines, etc., to meet complex application needs. In addition, the drive has a wide voltage range and high overload capacity (such as 250% overload). Safety features (such as inverter enable input) and integrated SERCOS The interface and other features are designed specifically for machines with fast cycle rates, such as food and packaging machinery. The dynamic brushless servo motor is equipped with a high-resolution encoder and electronic nameplate, achieving precise positioning and fast response, suitable for the strict requirements of modern industrial automation systems.
Technical specifcations for MC-4/11/22-400
Brand and place of origin: This product is a component of ELAU's (now a brand under Schneider Electric) PacDrive MC-4 servo system and is produced in France, reflecting its international quality and advanced technological background.
Power Supply and Power:
Power Supply Voltage: Typically supports DC24V, with some information mentioning a maximum power range of 380V to 480V+/-10%, meeting voltage requirements in different industrial environments.
Power density: The product adopts a compact design and integrates an efficient cooling system, achieving high power density and providing powerful power support in various industrial automation applications.
Control performance:
Control Algorithm: Advanced control algorithms are used to achieve precise control of the motor, including position, speed, and torque control, providing excellent performance and stability.
Response speed: With fast response capability, it is suitable for demanding applications that require high-precision motion control and high-speed operation.
Communication interface and protocol:
Supports multiple communication interfaces, such as CANopen, EtherCAT, and SERCOS interfaces, for easy integration and communication with other industrial equipment.
By communicating with the PacDrive controller through fiber optic cables, a decentralized structure is achieved to improve the flexibility and reliability of the system.
Function and Features:
Standard configuration includes single loop and multi loop processing functions, suitable for application scenarios that require high-precision positioning.
It has a 250% overload capacity, enhancing the reliability and durability of the system.
Equipped with safety features, such as enabling input for inverters, improves operational safety.
Mechanical and installation:
Compact design, sturdy casing, suitable for wall mounted installation, space saving and easy maintenance.
A software regulator with integrated power supply unit, final stage, and one axis, which does not require user programming and simplifies the installation and debugging process.
Environmental adaptability:
High protection level, suitable for durability requirements in industrial environments.
The working temperature range is wide and can adapt to temperature changes in different industrial environments.
